Linear Constant-Speed Reciprocating Friction and Wear Tester
The Linear Constant-Speed Reciprocating Friction and Wear Tester is a specialized instrument for evaluating friction and wear performance of materials and surface coatings under linear constant-speed sliding conditions. The instrument can accurately measure friction coefficient, wear depth, wear width, and wear volume under various loads, sliding speeds, stroke lengths, and temperature conditions, in dry or lubricated environments. The testing process is computer-controlled with real-time data acquisition and graphical display, suitable for material research, process evaluation, and quality control.
Application
Friction and wear testing of metallic materials.
Wear resistance evaluation of non-metallic materials (plastics, rubber, composites).
Tribological study of surface coatings, platings, and surface-modified layers.
Testing of solid and liquid lubricants’ friction performance.
Analysis of material surface processing effects on friction and wear behavior.
Material failure mechanism and reliability research.
Industrial product quality inspection and process control.
Standards
GB/T 3960-2016 Plastics – Determination of Sliding Wear Properties
GB/T 12444 Metallic Materials – General Friction and Wear Testing Methods
ASTM G133 Linear Reciprocating Sliding Wear Test
ASTM G99 Pin-on-Disk Wear Test (related friction measurement requirements)
ISO 7148 Sliding Friction and Wear Testing (relevant sections)
DIN 50324 General Principles of Friction and Wear Testing
Parameters
| Parameter | Specification |
|---|---|
| Test Load Range | 30–1000 g (weight loading) |
| Automatic Loading Range | 10–200 N |
| Test Load Measurement Accuracy | 0.2% F.S |
| Reciprocating Stroke | 0.5–50 mm (adjustable) |
| Reciprocating Frequency | 2–30 Hz |
| Sliding Speed | 0.1–20 mm/s |
| Heating Furnace Temperature | Room temperature – 300℃ |
| Furnace Sample Size | Φ15–40 mm |
| Load Range in Heated State | 0.3–80 N |
| Friction Force Measurement Range | ≤100 N |
| Wear Load Range | ≤40 g |
| Wear Depth Measurement Range | ±0.5 mm |
| Wear Depth Measurement Accuracy | 0.02 µm |
| Control Method | Computer automatic control |
| Data Processing | Real-time curve display and data storage |
Features
Linear constant-speed reciprocating motion ensures stable, repeatable friction conditions.
Wide load range supports both weight and automatic loading.
Independently adjustable sliding speed and stroke to simulate various working conditions.
Supports high-temperature testing for realistic service environment simulation.
Integrated online wear depth measurement allows quantitative wear analysis.
Computer-controlled data acquisition ensures synchronized friction coefficient and wear measurement.
Long-term stable operation suitable for research and industrial testing.
