High Temperature Tribometer
The High-Temperature Tribology Tester is designed to perform friction and wear tests using ball-on-disk and pin-on-disk configurations. It is suitable for simulating dry friction, oil lubrication, and high-temperature friction conditions. The device integrates a test force loading system, friction measurement system, sample fixture, high-temperature heating system, and temperature control system. By adjusting temperature, load, speed, and friction pair materials, you can comprehensively evaluate wear resistance and lubrication performance under varied conditions.
Applications
You can use this tester for:
High-temperature friction and wear testing of metals, ceramics, and polymer materials
Friction tests under different lubrication states, including oils and gases
Dry, oil-lubricated, and gas-lubricated tests at elevated temperatures
Comparative wear evaluation and material performance assessment in high-temperature environments
Industrial product development, material selection, and quality control
Standards
ASTM G99: Standard Test Method for Wear Testing
ASTM G133: High-Temperature Friction and Wear Test Method
ISO 20808: Solid Material Friction and Wear Test
GB/T 3147: Methods for Determining Friction Material Wear Performance
Technical Specifications
| Parameter | Range / Specification |
|---|---|
| Test Force Loading Range | 0.1–10 N, 10–200 N |
| Maximum Friction Torque | 2.5 Nm |
| Spindle Maximum Speed | 2000 rpm |
| Heating Temperature Range | Room temperature – 1000℃ |
| X-Axis Adjustable Friction Radius | 0–35 mm |
| Z-Axis Adjustable Lift Height | 0–50 mm |
| Test Medium | Dry friction, circulating gases (N₂, CO₂, He, Ar, etc.), oil |
| Time Display & Control | 0–999999 s/min |
| Revolution Display & Control | 0–999999999 r |
| Machine Weight | Approx. 90 kg |
| Power Supply | 220 V, 16 A |
| Power | 1.5 kW |
Features
Dual Friction Modes: Supports ball-on-disk and pin-on-disk testing to meet different experimental requirements
High-Temperature Capability: Adjustable up to 1000℃ for testing high-temperature materials
Multiple Lubrication Options: Dry, oil, or inert gas lubrication (N₂, CO₂, etc.)
High-Precision Control: Accurate temperature control and force measurement ensure reliable testing
Adjustable Friction Radius and Height: Flexible X-axis radius and Z-axis lift height for customized testing
Long-Term Operation: Capable of prolonged high-temperature and high-load tests in demanding environments
