Adhesion Strength Tester

Whats/App: +86 156 1874 6768

Web: standard-groups.com

Application

The instrument is suitable for quantitative evaluation of adhesion and mechanical strength in a wide range of materials and bonded structures, including:

T-peel strength measurement of laminated materials

180° peel strength testing of adhesive joints

Tensile strength testing of bonded or flexible materials

Tear resistance testing of films, textiles, and papers

Surface adhesion force evaluation of coatings and bonded layers

Typical test samples include:

Adhesive tapes and laminates

Films, sheets, and flexible packaging materials

Paper, paperboard, and coated paper products

Textiles and nonwoven fabrics

Bonded polymer and composite materials

Standards

JIS L 1066 (Testing Methods for Woven Fabrics)

JIS L 1085 (Testing Methods for Nonwoven Fabrics)

JIS L 1086 (Testing Methods for Textile Products)

JIS P 8139 (Determination of Adhesion and Peel Strength of Paper and Board)

Parameters

Parameter	Specification
Measurement range	Load cells available: 0–100 gf, 0–2000 gf
Traveling speed	Clamp traveling speed: 50–500 mm/min
Measurement speed	Opposing clamp speed: 100–1000 mm/min
Travel distance	Stroke per clamp: 150 mm
Specimen size	Maximum: 200 mm × 75 mm
Output signal	0 to ±5 V (within ±0.05% FS)
Frequency response	2 kHz / −3 dB
Operating environment	Temperature: 0–50 °C
	Relative humidity: ≤85%, non-condensing
Power supply	AC 100 V, 50/60 Hz
Dimensions	W 630 mm × D 310 mm × H 350 mm

Features

Wide measurement capability from very low to relatively high adhesion forces

Supports multiple test modes, including T-peel, 180° peel, tensile, tear, and surface adhesion tests

Desktop-type design suitable for laboratory and on-site testing

Portable structure allows convenient measurements in different locations

Simple zero balance and calibration procedures enable quick and intuitive operation

Stable opposing-motion mechanism ensures consistent and repeatable test results
