Bursting Strength Tester
Get a quote：
Web: qinsun-lab.com
Email：info@qinsun-lab。com
Standard
ASTM D3786: Hydraulic bursting strength test method for textiles (Diaphragm method).
ISO 13938-2: Textile bursting characteristics – Air pressure method for bursting strength and expansion.
IWS TM 29: International Wool Bureau Standard for fabric bursting resistance.
EDANA 80.4.2002: Recommended test method for non-woven fabric bursting strength.
NEXT 22: Determination of fabric bursting properties.
GB/T 7742.1: Chinese National Standard for textile bursting strength (Equivalent to ISO 13938-2).
Technical Parameters
| Parameter | Specification |
|---|---|
| Max. Bursting Force | 1.50 MPa |
| Test Modes | Manual / Automatic / Optional (Dual-Button + Foot Switch) |
| Accuracy | ±0.2% F.S. |
| Bursting Surface Diameter | 30 mm / 30.5 mm / 31 mm / 35.7 mm / 79.8 mm / 112.8 mm (Optional) |
| Bursting Membrane Size | 155.8 mm |
| Pressurization Method | Pneumatic Air Pressure |
| Pressurization Rate | 1–100 kPa/min (Adjustable) |
| Sample Fixing | Pneumatic Clamp |
| Output Forms | Printout / Display / Real-Time Graphic Display / Online Communication |
| Report Format | Bursting Strength, Film Pressure, Bursting Height, Bursting Time, Statistical Analysis |
| Bursting Height Accuracy | 70 ±1% |
| Power Supply | AC 220V ±10%, 50Hz (Customizable 110V/60Hz) |
| Dimensions | 800mm × 700mm × 1100mm |
| Net Weight | 115 kg |
| Software Features | Real-Time Data Acquisition, Statistical Analysis, Exportable Reports (PDF/Excel) |
| Safety Protections | Emergency Stop, Overload Protection, Auto Pressure Release |
