Large-Area LED Solar Simulator 3A+
Get a quote：
Web: qinsun-lab.com
Email：info@qinsun-lab。com
TheLarge-Area LED Solar Simulator 3A+is designed to provide a controllable, repeatable, and standardized “solar environment” for testing large photovoltaic (PV) modules in laboratory settings. You use this simulator to replicate real solar irradiance across meter-scale areas, allowing comprehensive performance evaluation of PV modules under precise, uniform, and programmable light conditions. Its LED-based system ensures high spectral accuracy, exceptional uniformity, instant response, and long-term reliability, making it suitable for both R&D and production line testing of large-scale photovoltaic products.
Standards
(1) IEC 60904-9 – Photovoltaic Devices: Performance Requirements for Solar Simulators
(2) ASTM E927 – Standard Guide for Laboratory Simulation of Solar Radiation
(3) IEC 60904-3 – Measurement of Photovoltaic Current-Voltage Characteristics
(4) ISO 9060 – Solar Irradiance Measurement and Calibration Standards
(5) IEC 61853 series – Photovoltaic Module Performance Testing under Standard Test Conditions
Technical Parameters
| Performance Item | Technical Specification |
|---|---|
| Effective Irradiation Area | Up to meter-scale (e.g., 1.2 m × 2.4 m) |
| Irradiance Uniformity | Typically better than ±2% |
| Spectral Matching | Multi-channel LEDs (A+/B+) covering UV, visible, and IR bands |
| Flash Duration | Milliseconds, programmable |
| Switching Time | Instantaneous, flicker-free output |
| LED Lifespan | Tens of thousands of hours |
| Adjustable Spectrum | Programmable to replicate AM1.5G, AM0, and custom solar spectra |
| Cooling System | Liquid or air-based thermal management for high-power LEDs |
| Control System | Intelligent calibration with distributed sensors and software interface |
Send product request
