Mobile Floor Scrubber Aging Life Test Equipment
Get a quote：
Web: qinsun-lab.com
Email：serving@qinsun-lab。com
TheMobile Floor Scrubber Aging Life Test Equipmentis designed to evaluate the long-term durability and operational lifespan of floor scrubbers. You can simulate real-world cleaning conditions by laying materials such as carpet, hard flooring, or tiles on the test platform. Controlled via PLC, the system drives floor scrubbers in reciprocating motion at adjustable speeds while collecting temperature data at multiple points. Integrated water supply and extraction systems replicate cleaning operations. Test data, including voltage, current, power, speed, stroke, temperature, and cycle counts, can be exported via USB for analysis. This equipment ensures high versatility, simple operation, convenient control, and low failure rates for testing multiple floor scrubber models under realistic usage conditions.
tandards
-
IEC 60312-2010 – Household and Similar Electrical Appliances – Methods for Measuring Performance
-
GB/T 20291.1-2014 – Household Vacuum Cleaners – Test Methods for Performance and Durability
-
GB/T 28291-2012 – General Requirements and Test Methods for Robotic Cleaning Appliances
-
IEC – Household and Similar Appliances – Cleaning Performance Testing Methods
Features
-
Accurately simulatesreal-world floor conditionsusing varied floor surfaces
-
Monitorstemperature, electrical parameters, and operational cyclesat multiple points
-
Supportsconfigurable speed, stroke, and cycle settingsfor versatile testing
-
Integratedwater supply and extraction systemreplicates actual cleaning operations
-
Data collected via PLC can be exported viaUSB for analysis
-
Compact and organized design reduces testing footprint while supporting multiple stations
Technical Parameters
| Item | Specification |
|---|---|
| Test Stations | 6 stations, 3 stations per group |
| Test Voltage & Current | DC: 0–60V; Current per station: 0–20A |
| Effective Travel of Test Table | 100–600 mm (adjustable) |
| Speed of Test Fixture | 150–800 mm/s (settable) |
| Electrical Parameters | Current, voltage, power, temperature |
| Cycle Setting | 0–9999999 (settable) |
| Counting Range | 0–999999 s (settable) |
| Test Modes | Time on/off setting, test count mode |
| Water Adding Time | 0–999999 s (settable) |
| Water Draining Time | 0–999999 s (settable; waste water is directly discharged) |
| Temperature Points | 2 points per station, total 8 points |
| Temperature Probe | Type K; Temperature range: 0–200℃ |
| Drive Mode | Servo motor reciprocating drive mechanism, mechanical transmission mechanism |
| Control Method | Mitsubishi PLC (Japan) + 7-inch touch screen |
| Test Data Acquisition | Voltage, current, test time, count, speed, stroke, temperature |
| Data Export | USB |
| Equipment Dimensions | 3500×1250×1680 mm |
| Equipment Power Supply | 220V 50Hz, 2.5KW |
