High-Specification Scratch Resistance Tester
Get a quote：
Web: qinsun-lab.com
Email：serving@qinsun-lab。com
Application
The Scratch Resistance Tester is primarily used for the following materials and fields:
Rigid organic materials;
Coatings and adhesives;
Powder coatings;
Anodized materials;
Soft metals;
Plastics and glass;
Quality assessment of protective coatings and adhesives;
Material limit performance testing.
Standards
GB/T 17657‑2022 – Test Methods for Properties of Wood-Based Panels and Decorative Facing Panels
GB 4943.1 – Safety of Information Technology Equipment – Part 1: General Requirements (Clause 2.10.6.6)
GB 4706.1 – Safety of Household and Similar Electrical Appliances – Part 1: General Requirements (Clause 21.2)
AS/NZS 2924.2 – Performance of Kitchen Worktops and Surface Materials – Part 2: Determination of Resistance to Abrasion and Scratching
ASTM C217 – Test Method for Resistance to Abrasion of Ceramic Glazed Tiles
BS EN 438-2 – Physical and Mechanical Properties of High Pressure Laminates (HPL) – Part 2: Test Methods
BS EN 13310 – Performance Requirements for Kitchen Worktops and Surface Materials
BS EN 14323 – Test Methods for Scratch Resistance, Abrasion Resistance and Chemical Resistance of Furniture Surfaces
DIN 68861‑4 – Mechanical Properties of Furniture Surfaces – Part 4: Scratch Resistance
DIN 53799 – Methods for Determining the Hardness of Plastics (Scratch/Indentation)
Parameters
| Item | Details |
|---|---|
| Control System | PLC + Windows System |
| Operation Interface | 12-inch color embedded industrial computer, Chinese/English switchable |
| Printing Function | WiFi-connected printer |
| Motor | Stepper motor + reducer |
| Force Weights | Standard configuration: 5N, 6N, 7N, 8N, 10N (other specifications optional) |
| Test Speed | Factory set at 5r/min, adjustable range: 0–60R/min |
| Spacing | Scratch spacing can be set arbitrarily |
| Sample Size | 100*100mm, with a 6.5mm hole in the center |
| Scratching Head | Standard: diamond stylus; optional: 4.84.8R2.5 |
| Speed Display | Adjustable on the industrial computer |
| Dimensions | 550310520mm |
| Power Requirement | 220V, 60A |
Features
PLC + Windows dual-system control with a simple and intuitive interface;
Color touchscreen industrial computer with Chinese/English language switching for easy parameter setup;
WiFi printer connectivity for convenient data logging;
Stepper motor drive paired with a reduction gearbox ensures stable low-speed rotation;
Adjustable weights enable testing with varying force values;
Scratch spacing freely configurable to meet diverse standard requirements;
Optional diamond scraper head, durable and replaceable;
High-end version offers enhanced precision and broader applicability.
