High-Low Temperature Humidity Test Chamber
Applications
High and Low Temperature Humidity Test Chamber is designed for performance and reliability testing of electric vehicle power batteries. It can be integrated with battery performance testing systems and is also suitable for research and development, matching, and other tests involving power batteries and battery management systems.
Standards
GB/T 2423.1: Environmental testing methods for electrical and electronic products - Test A: Low-temperature test method
GB/T 2423.2: Environmental testing methods for electrical and electronic products - Test B: High-temperature test method
GB/T 2423.3: Environmental testing methods for electrical and electronic products - Constant humidity and heat test method
GB/T 2423.4: Environmental Testing Methods for Electrical and Electronic Products - Alternating Humidity and Heat Test Method
GB/T 10586-2006: Technical Conditions for High and Low Temperature Test Chambers
GB/T 10592-2023: Technical Conditions for High and Low Temperature Test Chambers
IEC 62660-4 Lithium-ion batteries for electric road vehicle propulsion
GB/T 31484-2015 Cycle life requirements and test methods for power batteries used in electric vehicles
Features
1. Comprehensive Safety Protection: Equipped with explosion-proof devices, automatic fire suppression systems, and gas detection units to ensure testing safety.
2. Intelligent Operation and Energy Efficiency: Supports program control and remote monitoring, utilizes fluorine-free refrigerants and energy-saving technologies, and complies with environmental standards.
Parameters
| No. | Item | Specifications |
|---|---|---|
| 1 | Inner Chamber Volume | 12 m³ |
| 2 | Inner Chamber Dimensions | 3000mm (W) × 2000mm (D) × 2000mm (H) |
| 3 | Temperature Range | -45°C ~ +100°C (adjustable) |
| 4 | Temperature Fluctuation | ≤ 0.5°C (no load, steady state) |
| 5 | Temperature Uniformity | ≤ 2°C (no load, steady state) |
| 6 | Temperature Deviation | ≤ ±2°C (no load, steady state) |
| 7 | Heating Rate | ≥ 2°C/min (room temperature ~ 85°C, with non-linear load of 1000kg battery pack) |
| 8 | Cooling Rate | ≥ 1.0°C/min (room temperature ~ -40°C, with non-linear load of 1000kg battery pack) |
| 9 | Humidity Range | 20% ~ 98% RH (adjustable) |
| 10 | Humidity Deviation | - Humidity > 75% RH: ≤ ±2~3% RH- Humidity ≤ 75% RH: ≤ ±5% RH |
| 11 | Humidity Fluctuation | ≤ 2% RH |
| 12 | Humidity Uniformity | - Humidity > 75% RH: ≤ ±2~3% RH- Humidity ≤ 75% RH: ≤ ±5% RH |
| 13 | Air Pressure Balance System | Equipped with an air pressure balance valve, which opens automatically under a certain pressure difference |
Accessories
1.Integrated Fire Suppression: Automatic extinguishing system triggered by thermal or smoke sensors.
2.Gas Detection Sensors: Real-time monitoring for $H_2$, $CO$, and other battery vent gases.
3.Cable Access Ports: Sealed ports (typically $100text{mm}$) for connecting the battery to external cyclers or BMS testers.
4.Pressure Balance Valve: Mechanical relief valve to equalize internal and external pressure during rapid temperature changes.
5.Multi-Pane Observation Window: Heated glass to prevent frost and condensation during low-temperature or high-humidity runs.
Send product request
Other supplier products
 |
Metallic Cables and Wire Ropes Mechanical Property Testing Machine | Standard YY/T 0812-2010 (China): Specifies mechanical testing protocols for metal cables/cables used in fracture fixation, including fatigue stren... |
 |
STD Battery short-circuit tester丨STD Battery short-circuit chamber | Product Introduction Battery Short Circuit Tester is a device that can be applied to the external short circuit test process of lithium ion batter... |
 |
Mechanical load testing machine for photovoltaic modules | The Mechanical Load Testing Machine for Photovoltaic Modules is engineered to evaluate the mechanical durability of both crystalline and thin-film ... |
 |
Air Flow Drying Rate Tester | Applications The Airflow Method Fabric Drying Rate Tester is an automated testing instrument designed to measure the drying rate of textiles in ac... |
 |
