Laboratory Simulated Car Wash Tester

Get a quote:

Web: qinsun-lab.com

Email:serving@qinsun-lab。com

The Laboratory Simulated Car Wash Tester is a specialized testing device designed to replicate automatic car wash tunnel conditions under laboratory settings. Through rotating brushes, controllable specimen movement, and spraying cleaning media containing synthetic dirt, the equipment applies repeated mechanical stress to painted surfaces, protective films, and plastic components. It evaluates materials’ scratch resistance, abrasion resistance, and appearance changes under simulated car wash processes.

Application

Based on the application of similar devices in automotive coating, surface materials, and full vehicle component testing, this equipment is suitable for:

Wash durability testing of organic coatings on vehicles and components

Scratch resistance evaluation of automotive clear coats, color coatings, and multilayer coating systems

Assessment of paint protection films (PPF) wash resistance and appearance retention

Abrasion testing of plastic exterior parts (bumpers, trims, covers)

Evaluation of functional coatings applied on metal or plastic substrates

R&D verification and quality control of surface materials under simulated car wash tunnel conditions

Standards

The tester is designed to meet and execute the following standards:

ISO 20566:2021 – Paints and varnishes – Determination using laboratory-scale car wash machines

ISO 13076 – Visual assessment of coating surface appearance

ISO 2813 – Measurement of gloss of coatings

ISO 13803 – Determination of coating haze

ISO 7724 – Color measurement and evaluation of color differences

Parameters

ItemTechnical Specification
Equipment Dimensions Approx. W3100 × D950 × H1800 mm
Equipment Weight Approx. 450 kg
Main Material SUS 304 Stainless Steel
Test Environment Temperature 23 ± 3 ℃
Test Environment Humidity 50 ± 5 % RH
Test Medium Clean water + Silicon dioxide (SiO₂)
Medium Temperature 15–30 ℃
Brush Direction Clockwise / Counterclockwise
Brush Speed 70–127 ± 5 rpm
Brush Cycle 1–999 cycles
Wash Medium Capacity 80 L
Specimen Thickness 1.5–3.5 mm
Specimen Size 155 × 305 mm (up to 4 pieces) or 310 × 610 mm (1 piece)
Platform Speed 5.0 ± 0.2 m/min
Nozzle Flow Rate 2.2 ± 0.2 L/min
Nozzle Pressure 300 ± 50 kPa
Power Supply AC 220 V, 2.2 kW, 50 Hz
