Ozone Aging Chamber
Get a quote：
Web: qinsun-lab.com
Email：serving@qinsun-lab。com
The Ozone Aging Chamber is used to test the colorfastness and aging properties of materials such as rubber, textiles, and fabrics when exposed to ozone. This instrument consists of an ozone generator, fan, baffle, specimen holder, and specimen chamber. The ozone generator utilizes a high-voltage transformer for grid discharge. The generator is positioned upstream of the low-pressure fan. The ozone generator injects ozone into the test chamber. The specimen holder features separable clamps mounted on a wire slip ring, accommodating specimens of various sizes.
Standards
GB/T 11039.3-2005 Textiles - Color fastness tests - Resistance to atmospheric pollutants - Part 3: Atmospheric ozone
ISO 105-G03:1993 Textiles - Colour fastness tests - Part G03: Resistance to atmospheric ozone
GB/T 7762-2014 Vulcanized rubber or thermoplastic rubber - Resistance to ozone cracking - Static tensile test
GB/T 13642-2015 Vulcanized Rubber or Thermoplastic Rubber - Resistance to Ozone Cracking - Dynamic Tensile Test
AATCC 109-2016 Resistance to Ozone in Low-Humidity Atmosphere
AATCC TMe Test Method for Resistance to Ozone in High-Humidity Atmosphere
Features
High-Efficiency Ozone Generation:Ensures stable and uniform ozone concentration for consistent test results.
Closed-Loop Ozone Control:Automatically monitors and maintains the desired ozone levels during testing.
Rotating Sample Rack:Accommodates up to 24 specimens, ensuring uniform exposure to ozone.
User-Friendly Interface:Pre-set and current parameters are displayed on-screen for easy operation and monitoring.
Colorfastness Assessment:Simultaneously tests one specimen against a control standard to determine ozone-induced fading.
Flexible Environmental Simulation:Supports both low- and high-humidity ozone aging tests.
Parameters
| Item | Specifications |
|---|---|
| Control Mode | Automatic |
| Ozone Range | 1–1000 ppm |
| Sample Rack Rotation Speed | 1–10 RPM (adjustable) |
| Sample Fixture Material | Stainless steel |
| Main Body Material | Stainless steel |
| Weight | 155 kg |
| Power Supply | 220V 50Hz |
| Overall Dimensions (L×W×H) | 1020mm×1000mm×1650mm |
