Toilet Corrosion Test Chamber (HCl and Ammonia)
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
Toilet seat hydrochloric acid and ammonia corrosion tester is used for testing to evaluate the ability of toilet seat products to provide adequate rust protection against detergents and urine. The test chamber by simulating ammonia components, hydrochloric acid solvent body, medium on the toilet electrical components or other inorganic cover layer in condensation conditions of corrosion test. The test chamber is electronic toilet sampling and testing of product quality supervision and inspection institute 3 testing organizations and toilet manufacturers of essential test equipment.
Standards
GB/T 4706.53-2024: Safety of household and similar electrical appliances - Part 2: Particular requirements for commercial dishwashing machines, glass-washing machines and utensil-washing machines
IEC 60335-2-84:2019: Household and similar electrical appliances - Safety - Part 2-84: Particular requirements for commercial dishwashing machines, glass-washing machines and utensil-washing machines
Features
1. Precise and Controllable Corrosive Environment: It can stably maintain specific concentrations of ammonia (0.055%±0.005%) and hydrochloric acid (0.0005%±0.0002%), using a gas cylinder method for gas generation and a corrosion-resistant mass flow meter for flow control, ensuring precise matching of the corrosive medium concentration and flow rate to test requirements.
2. Standardized Test Conditions: It requires operation in a cleanroom environment without strong airflow. Temperature (25℃±2℃) and humidity (<75% RH) are strictly controlled to ensure the repeatability and reliability of test results.
3. Strong Sample Load Capacity Adaptability: The equipped sample test rack has a maximum load capacity of ≥50kg and can maintain a vertical placement at 90°±2°, adapting to the fixing requirements of large items such as toilet seats.
4. Reasonable structural dimensions: The inner casing (W1200×H1200×D1200mm) is large enough to accommodate a toilet, while the outer casing (approximately W2350×H1700×D1500mm) balances operating space with equipment integration.
5. Low operating energy consumption: The installed power is only 400W, and it is compatible with AC 220V universal power supplies, resulting in high cost and environmental adaptability.
Technical Parameters
| No. | Main Parameters | Specifications |
|---|---|---|
| 1 | Inner box size | W1200×H1200×D1200mm |
| 2 | Outer box size | About W2350×H1700×D1500mm |
| 3 | Test temperature | Room temperature |
| 4 | Ammonia concentration | 0.055%±0.005 |
| 5 | Hydrochloric acid concentration | 0.0005%±0.0002 |
| 6 | Test gas generation method | Cylinder method |
| 7 | Test gas control | Calculate by volume ratio (per test requirements), then control flow rate via anticorrosive mass flow meter |
| 8 | Sample test frame | Maximum load ≥50kg; placed vertically at 90°±2° |
| 9 | Use environment & temperature | Clean room (no strong airflow); temperature 25℃±2℃ |
| 10 | Use environmental humidity | <75% RH |
| 11 | Equipment power supply | AC 220V 50/60Hz |
| 12 | Installed power | 400W |
Accessoriess
1. Hydrochloric acid and ammonia corrosion test chamber 1 set
2. A set of exhaust gas filtering device
3. ammonia gas cylinder 1 bottle
4. Matching special pressure reducing valve 1pc
5.1 bottle of hydrochloric acid
