Syringe barrel pressure integrity tester
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Application
This tester is suitable for evaluating a wide range of medical devices with Luer-type and non-Luer connections, including:
(1) Disposable syringes of various capacities (1–200 mL) – testing piston and barrel sealing integrity.
(2) Infusion and injection systems – verifying leakage under positive and negative pressure conditions.
(3) Catheters – ensuring connection sealing under axial and lateral forces.
(4) Blood transfusion sets – testing reliability of sealing components under pressurized conditions.
(5) Production line quality control – confirming consistent tight-fitting performance across batches.
(6) Research and development – assessing new syringe and piston designs for leak prevention.
Standards
The tester complies with the following domestic and international standards:
(1) GB/T 15810-2001: Disposable sterile syringes (China)
(2) YY/T 0909-2013: Standard for disposable medical syringes (China)
(3) ISO 7886-1: Sterile hypodermic syringes for single use – Part 1: Syringes for manual use (International)
(4) ISO 7886-2: Sterile hypodermic syringes – Part 2: Syringes for use with injectors (International)
Parameters
| Parameter | Specification |
|---|---|
| Lateral force | 0.25 – 3.00 N, error ≤ ±0.5% |
| Axial pressure | 100 – 400 kPa, error ≤ ±2% |
| Nominal capacity | 1 – 200 mL (optional) |
| Test time | 0 – 9999 s, adjustable |
| Working temperature | 5 – 40 ℃ |
| Relative humidity | 45 – 80% |
| Standards compliance | GB/T 15810-2001. YY/T 0909-2013. ISO 7886-1. ISO 7886-2 |
Accessories
(1) Intelligent manipulator – 1 set
(2) Force measurement mechanism – 1 set
(3) Distance measuring group – 1 set
(4) Printer – 1 set
(5) Operation manual – 1 set
(6) Power cable – 1 set
