Expansion Tank Static Pressure Test Machine
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
The Expansion Tank Static Pressure Test Machine is a specialized system designed to evaluate the static pressure performance and leak resistance of automotive expansion tanks. You can adjust the static pressure from 0 up to a maximum of 5 bar, while controlling the flow rate of each sample from 0 to 8 liters per hour. The system includes indirect chamber heating for safety (Explosion Protection Level 1), automatic leak detection, and fail-safe shutdown of defective samples, providing a reliable and efficient solution for expansion tank testing.
Application
The Expansion Tank Static Pressure Test Machine is suitable for a variety of automotive component testing applications:
Expansion Tanks: Evaluate static pressure resistance, leakage, and functional performance.
Coolant System Components: Test caps, valves, and connectors under controlled static pressure.
Material Durability Testing: Assess long-term reliability of plastic, metal, and composite tank materials.
Quality Control: Ensure compliance with OEM and supplier specifications for automotive cooling systems.
R&D and Certification Testing: Support component development, validation, and system integration.
Typical test products include automotive expansion tanks, coolant reservoir tanks, and associated components requiring static pressure evaluation.
Standards
The system supports compliance with major automotive engineering standards:
VW TL889 (4.1) – Volkswagen Group technical specification for interior and related component functional performance.
ESDG93-8A080-AA (3.6) – Ford engineering specification for component functionality and reliability.
GMW15310 (3.2.1.2) – General Motors global standard for material and component performance testing.
QV17004D (3.2.6) – BMW group specification for system component functionality and durability.
Parameters
| Parameter Category | Details |
|---|---|
| Test Bench Dimensions | 2200 × 2240 × 1550 mm (W × H × D) |
| Chamber Dimensions | 1000 × 800 × 1000 mm (W × H × D) |
| Rated Power | 9.5 kW |
| Test Medium | Glycol/Water |
| Pressure Range | 0 … 5 bar |
| Flow Rate per Sample | 0 … 8 l/h |
| Pressure Type | Static |
| Test Medium Temperature Range | 25 … +150°C |
| Environmental Temperature Range | 25 … +150°C |
| Test Channels | 6 |
