Manual HEPA/ULPA Filter Scanning Test System
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
The Manual HEPA/ULPA Filter Scanning Test System is designed for quality control of HEPA and ULPA air filters according to ISO 29463 and EN 1822 standards. The system uses a manual scanning approach suitable for existing filter test benches, providing accurate leakage detection, local and overall efficiency measurement, and compliance verification.
Application
(1) Filter Production Control: Ensures HEPA and ULPA filters meet ISO 29463 and EN 1822 separation efficiency standards.
(2) Air Purification Industry: Quality testing of filters used in industrial air-cleaning systems and household air purifiers.
(3) Medical Equipment: Testing HEPA filters used in medical devices for efficacy verification.
(4) Automotive Industry: Evaluating HEPA filters in vehicle air purification systems.
(5) Cleanrooms and Laboratories: Periodic inspection and maintenance of high-efficiency air filters.
(6) HVAC Systems: Performance evaluation in industrial and commercial HVAC applications.
Standards
(1) GB/T 14295-2008 – High-efficiency air filters
(2) GB/T 13554-2020 – High-efficiency air filters
(3) GB/T 14295-2019 – Air filters
(4) GB/T 6719 – Bag-type dust collector technical requirements
(5) GB/T 6165-2021 – HEPA filter performance: efficiency and resistance
(6) ISO 29463-4 – Local efficiency and leakage detection (same as EN 1822-4)
(7) ISO 29463-5 – Overall separation efficiency
(8) EN 1822-4 – Local efficiency and leakage test
(9) EN 1822-5 – Overall separation efficiency
(10) ISO 29463-3 – Most Penetrating Particle Size (MPPS) test for filter media
(11) ISO 14644-3 – Cleanrooms and controlled environments
(12) IEST-RP-CC034 – HEPA filter performance standard
(13) ASTM D6830-02 – HEPA filter testing methods
Parameters
| Parameter | Unit | Value |
|---|---|---|
| Maximum Test Flow Rate | m³/h | 1200 |
| Differential Pressure Range | Pa | 0–400 |
| Maximum Sample Dimensions | mm | 1220 × 610 × 300 |
| Aerosol Operating Medium | – | DEHS, PSL |
| Gas/Air Supply | bar | 6 |
| Power Supply | V/A | 230 VAC, 10 A |
| Test Medium Temperature | °C | 0–50 |
| Test Humidity | % RH | 0–100 |
| Operating Temperature | °C | 5–40 |
| Adjustable Adapter | – | Adaptable for different filter sizes |
| System Weight | kg | ~40 |
| System Dimensions (W × H × D) | mm | 450 × 600 × 350 |
