FPC Flex Durability Tester

Get a quote:

Whats/App: +86 185 0176 3615

Web: qinsun-lab.com

The FPC Flex Durability Tester is designed to evaluate the bending durability and fatigue life of flexible printed circuits (FPC), flexible flat cables (FFC), and similar flexible electronic components. The tester simulates repeated bending at controlled angles, speeds, and strokes to assess mechanical reliability and electrical continuity under cyclic flexing conditions. It is widely used in product development, quality control, and reliability testing of flexible electronic interconnects.

Application

(1) Flex durability testing of FPC (Flexible Printed Circuits) used in mobile s, tablets, laptops, and wearable devices.

(2) Fatigue life evaluation of FFC cables used in displays, cameras, and hinge structures.

(3) Reliability testing of flexible interconnects in automotive electronics and dashboards.

(4) Bending endurance testing of flexible circuits used in medical devices and precision instruments.

(5) R&D validation of new flexible substrate materials and circuit designs.

(6) Quality control testing during mass production of flexible electronic components.

(7) Electrical continuity monitoring during cyclic bending until failure.

Standards

(1) ASTM F392 – Standard Test Method for Flex Durability of Flexible Circuits.

Features

(1) Stepper motor drive ensures high positioning accuracy, low noise, and long-term stable operation.

(2) Program-controlled automatic origin reset, eliminating manual fixture repositioning.

(3) Touch screen controller for intuitive parameter setting and program input.

(4) Test angle, speed, test cycles, and motor return-to-origin can be digitally set via touch screen.

(5) Automatic counting with preset test cycles and auto-stop upon reaching the set value.

(6) Electrical conduction detection function with automatic stop when circuit disconnection occurs.

(7) Automatic stop when the specimen bends to the broken line and loses conductivity.

(8) Upper and lower moving fixtures simulate realistic flexing conditions.

Technical Parameters

ParameterSpecification
Test station 1
Test angle 10–180° (touch screen digital setting)
Test speed 10–120 times/min (touch screen digital setting)
Drive motor Stepper motor (standard), Servo motor optional
Test stroke 15–100 mm (manual adjustable)
Maximum fixture width 80 mm
Fixture configuration Upper moving fixture + lower moving fixture
Counter range 0–999,999 cycles (preset, auto-stop at break)
Test functions Angle, speed, cycles setting; continuity detection; auto stop; auto origin finding
Machine size (L×W×H) 450 × 380 × 700 mm
Machine weight Approx. 45 kg
Power supply AC 220V, 50 Hz
