Programmable three-station seat strength testing machine
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Standards
The machine supports compliance with major international and national standards:
GBI 5083-2019 – Automotive seats, seat anchorage, and headrest strength requirements and test methods.
ECE R17 – Automotive seat and headrest strength test methods and safety requirements.
Parameters
| Parameter Category | Details | Specifications |
|---|---|---|
| Machine Dimensions | Main Test Frame | 3500 × 2000 × 2200 mm |
| Control Cabinet | 600 × 600 × 1800 mm | |
| Power Distribution Cabinet | 800 × 600 × 1000 mm | |
| Power Supply | - | Single-phase AC 220 V, 50 Hz, 5 kW |
| Servo Electric Cylinders | Quantity & Purpose | 9 cylinders total, 6 for headrest/backrest static strength |
| Stroke & Accuracy | 600 mm, ±1% displacement, resolution 0.01 mm | |
| Maximum Thrust & Accuracy | 2 kN, ±1%, resolution 0.1 N | |
| Loading Position | 290 ± 0.25 mm above H-point | |
| Load Sensors | Capacity & Quantity | 2 kN, 6 sensors |
| Accuracy | ±1% | |
| Rated Output | 3 mV/V ± 0.025% | |
| Nonlinearity | 0.5% | |
| Non-repeatability | 0.2% | |
| Optical Encoder Displacement Sensors | Quantity | 9 pcs |
| Linearity | 0.05% F.S. | |
| Repeatability | 0.1% | |
| Other Parameters | Sampling Frequency | 2 kHz |
| Measurement Accuracy | Better than ±1% | |
| Control Accuracy | Better than ±1% |
Features
Full-range load capability without gear segmentation; adjustable loading speed.
High-performance servo electric cylinders with real-time automatic gain adjustment; adaptive filters enable testing from low to high stiffness automatically.
Measurement and control system uses NI high-performance motion control cards; modular and standardized architecture ensures flexibility, interchangeability, and easy maintenance.
Test data stored in a secure database with high confidentiality.
Software allows manual selection of curve points, slope calculation between points, curve scaling and shifting, and export of all sampled points to Excel; multiple curves can be overlaid for batch comparison and custom Excel report generation.
Simple calibration of load and displacement for user-friendly operation.
Modular design of the measurement and control system for easy maintenance.
Safety features include limit protection, overload protection, and software-set protection.
Accessories
Control and motion software suite (pre-installed).
Load cell calibration kit.
Optical encoder calibration fixtures.
Safety shields and limit switches.
Installation and operation manual.
Test Procedures
Ensure the sample is properly mounted and secured on the test frame.
Configure test parameters, including stroke, load, and displacement limits, using the software.
Start the test and monitor load and displacement curves in real-time on the control interface.
Record the results; curves and data can be exported for analysis.
Repeat for multiple samples if required.
Maintenance Information
Inspect servo cylinders, load sensors, and optical encoders regularly for wear or damage.
Calibrate load cells and displacement sensors periodically.
Keep the control cabinet and electronics free of dust and moisture.
Ensure all moving parts are lubricated according to the maintenance schedule.
Verify safety limit switches and overload protection functionality.
Send product request
Other supplier products
 |
Mechanical load testing machine for photovoltaic modules | The Mechanical Load Testing Machine for Photovoltaic Modules is engineered to evaluate the mechanical durability of both crystalline and thin-film ... |
 |
Drawer Slide Endurance Testing Equipment | Product Introduction Drawer slides are fundamental components in furniture, cabinetry, and various storage solutions, providing smooth and reliabl... |
 |
Incline Impact Tester，ISO 13355 angle impact tester for shipping materials | Whats/App: +86 156 1874 6768 Web: standard-groups.com The Incline Impact Tester is designed to evaluate the impact resistance of products, packag... |
 |
Advanced textile air permeability tester | Whats/App: +86 156 1874 6768 Web: standard-groups.com Application The Air Permeability Tester can evaluate a wide range of materials, including:... |
 |
Automatic Wyzenbeek abrasion tester | Whats/App: +86 156 1874 6768 Web: standard-groups.com Standard Test ASTM D3597：Standard Test Method for Resistance to Yarn Slippage in Woven Fab... |
