ICI Mace Snag Tester ASTM D3939
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
The ICI Mace Snag Tester is a laboratory device used to evaluate the tendency of fabrics—particularly knitted and woven textiles—to snag, pull, or tear during normal wear. It operates by rotating a specimen-covered drum while a weighted "mace" (studded with tungsten carbide pins) bounces on the surface, simulating accidental snagging on rough objects.
Standards
ASTM D3939 Standard Test Method for Snagging Resistance of Fabrics (Mace Test Method)
GB/T 11047 Textiles-Determination of fabrics snagging resistance-Mace test method
JIS L1058Test methods for snag of woven fabrics and knitted fabrics
Working Principle
The cylindrical specimen is placed on the revolving drum, and a chained hammer is placed on the surface of the specimen. When the drum rotates at a constant speed, the nail hammer makes random flip and bounces on the sample surface to hook the sample. The sample surface produces snagging. After the specified number of revolutions, compare with the comparison snag Lattuca for snag rating..
Accessories
·Snag rating box
·Tungsten carbide crochet hook (12pcs/bag)
·Felt jacket (4pcs/bag)
·Comparison snag Lattuca
Technical Parameters
·Specimen size: 220mm×330mm;
·Revolving drum diameter: 82mm;
·Revolving drum length: 210mm;
·Mace ball: Tungsten carbide head;
·Mace diameter : 31.8 mm;
·Mace height:135g;
·Mace protruding length: 9.5 mm;
·Mace plant needles: 11 tungsten needles;
·Needle exposed length: 10mm;
·Tip radius: R0.13mm;
·Guide bar working width: 125mm;
·Distance between the hammer and the guide bar：45mm;
·Stations: 4;
·Test speed: 60rpm;
·External dimension: 1007×508×405mm(L×W×H);
·Weight: about 90kg;
·Power supply: 1∮ ，AC220V，50Hz，3A
