Far Infrared Radiation Temperature Rise Tester GB/T 30127-2013
Get a quote:
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
Textile Far Infrared Radiation Temperature Rise Tester is used for various textiles including fibers, yarns, fabrics, nonwovens, and their products. It employs temperature rise testing to determine the far-infrared performance of textiles.
Standards
GB/T 30127-2013 :“Textiles - Testing and Evaluation of Far-Infrared Properties” Clause 4.2 Test Method for Far-Infrared Radiation Temperature Rise
T/CAS 115.5-2021:Health Care Textiles — Part 5: Far Infrared
Features
1. Features an industrial-grade color touchscreen display and control system with an intuitive human-machine interface that is simple to use and enhances operational convenience.
2. Utilizes an automatic measurement mode, enabling one-touch initiation to automatically complete the testing process.
3. Incorporates high-precision sensors capable of rapid response and accurate measurement of current temperature.
Parameters
|
Parameter Item |
Parameter Value |
|
Specimen Holder |
500mm distance from radiation source to specimen surface |
|
Radiation Source |
Main wavelength 5μm~14μm, radiation power 150W |
|
Specimen Irradiation Area |
φ60~φ80mm |
|
Temperature Range & Accuracy |
15℃~50℃, ±0.1℃ precision, ≤1s response time |
|
Specimen Types |
|
