Seatbelt Fabric Pilling Tester
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
The Seatbelt Fabric Pilling Tester is designed to simulate the pilling and wear of garments caused by seatbelt friction. It is suitable for testing the frictional effects of seatbelts on textiles and evaluating the pilling changes of garments under realistic seatbelt use conditions. The system allows adjustable test speed, automated counting, and precise simulation of human movement to ensure reproducible and accurate pilling assessment.
Application
Simulating pilling and wear on garments caused by seatbelt friction
Friction testing of seatbelts against textile materials
Evaluating garment durability under realistic seatbelt use conditions
Textile performance testing in automotive and apparel industries
R&D and quality control laboratories for garments and safety equipment
Technical Parameters
| Parameter | Specification |
|---|---|
| Swing Speed | 5–60 swings/min, adjustable |
| Swing Count | 1–99,999, programmable |
| Machine Weight | 100 kg |
| Power Supply | AC 220 V, 500 W |
| Control Interface | Color touch screen, user-friendly operation |
| Drive | Servo motor for stable and reliable rotation |
Features
User-friendly control: Color touch screen with intuitive human-machine interface
Automated testing: One-button start, automatic counting, and automatic stop after test completion
Realistic simulation: Microcontroller-based control accurately simulates human movement frequency and swing times
Adjustable speed: Test speed can be varied to evaluate different effects on textile samples
Stable operation: High-precision servo motor ensures smooth and reliable rotation
Accurate pilling assessment: Simulates real-life seatbelt friction on garments for reproducible results
