New Energy Battery Air Tightness Leak Tester
Whats/App: +86 156 1874 6768
Web: standard-groups.com
The New Energy Battery Air Tightness Leak Tester is an advanced intelligent detection system designed for sealing performance verification of battery packs and energy storage modules. It is equipped with a built-in smart leak detection system, supporting 1+99 programmable test procedures with one-key input. The 7-inch touchscreen provides intuitive operation, while safety light curtain protection ensures operator safety during testing. The system plays a critical role in ensuring battery safety by accurately detecting sealing integrity and preventing electrolyte leakage, short circuits, and ingress of water or dust.
Application
This equipment is used for air tightness and sealing performance testing of new energy battery packs, battery modules, energy storage systems, and power battery housings. It is suitable for production line quality inspection, incoming material testing, and final product verification. It ensures that battery systems meet waterproof and dustproof requirements, improving operational safety and long-term reliability in electric vehicles, energy storage systems, and industrial power applications.
Standards
(1) IEC 62619 (Safety requirements for industrial lithium-ion batteries)
(2) IEC 62133 (Safety requirements for portable sealed batteries)
(3) GB/T 31485 (Safety requirements for traction battery systems)
(4) GB/T 4208 (Enclosure protection standard)
(5) ISO 20653 (Degrees of protection for electrical equipment)
Parameters
| Item | Specification |
|---|---|
| Power Supply | AC 220V, 50Hz |
| Power Consumption | ≤20W |
| Air Source Requirement | 0.1–1.0 MPa dry compressed air |
| Inlet Interface | φ6 mm air tube |
| Test Interface | φ6 mm air tube |
| Test Pressure Range | 0–30 kPa |
| Sensor Resolution | 1 Pa |
| Test Accuracy | ±5 Pa |
| Communication Interface | RS232 / USB |
| Data Storage | Internal storage / USB export |
| Operating Temperature | -10°C to 55°C |
| Storage Temperature | -20°C to 70°C |
