ASTM D4491 compliant geomembrane tester

Whats/App: +86 156 1874 6768

Web: standard-groups.com

As the most cost-effective hydrostatic pressure tester, the Geomembrane Hydrostatic and Permeability Tester is not only powerful but also intelligent and efficient. The Geomembrane Hydrostatic and Permeability Tester is used to analyze the permeability of test materials. It can test hydrostatic pressure as water passes through the sample, and also test water resistance under constant water pressure, all while being secured by a special sealed system.

Application

It is used to test the hydrostatic pressure resistance and permeability coefficient of nonwoven composite geotextile (one cloth, one film, two cloth, one film) produced with polyethylene and polyurethane as the substrate and other materials under the specified water pressure difference conditions.

Standard Test

JTG E50 T1142-2006: Test Procedure for Geosynthetic Materials in Highway Engineering - Hydrostatic Pressure Resistance Test

JTS/T 245-2023: Test Procedure for Geosynthetic Materials in Water Transport Engineering

GB/T 19979.1-2005: Geosynthetic Materials - Impermeability Performance - Part 1: Determination of Hydrostatic Pressure Resistance

GB/T 19979.2-2006: Geosynthetic Materials - Impermeability Performance - Part 2: Determination of Permeability Coefficient

GB/T 17642-2025: Geosynthetic Materials - Nonwoven Fabric Composite Geomembrane

Feature

Can be used in one machine, equipped with 2 sets of test fixtures, in line with the national standard hydrostatic pressure and permeability coefficient test;

High precision pressure system, using gas-liquid mixed structure, to ensure stable pressure;

Solenoid valve control water inlet and outlet;

Equipped with percolating water collection device to prevent the collected percolating water from evaporating;

Equipment safety protection device.

Parameters

Technical ParametersSpecifications
Specimen Diameter 200mm
Perforated Plate Hole Diameter 3mm±0.05mm
Perforated Plate Hole Center Distance 6mm
Infiltration Water Collection Pipe Capacity 15ml
Permeable Water Collection Tube Precision 0.1ml
Pressure Range 0—2.5MPa
Pressure System Error ±2%
Equipment Dimensions (L×W×H) 900×600×14

Send product request

To: Standard International Group (HK) Limited
Your E-mail:
Message text:


Send to other suppliers

Other supplier products

Textile Point-to-Point Resistivity Tester
Textile Point-to-Point Resistivity Tester Whats/App: +86 156 1874 6768 Web: standard-groups.com Product Performance It is an essential instrument for the "Special Labor Protective Equipm...
Helmet Wearing Height Testing Machine
Helmet Wearing Height Testing Machine Whats/App: +86 156 1874 6768 Web: standard-groups.com The helmet wearing height testing machine is a testing device used to evaluate the comfort ...
ISO 12947 Martindale Abrasion Tester for Fabrics
