Flooring Materials Abrasion Resistance Tester
Whats/App: +86 156 1874 6768
Web: standard-groups.com
The Flooring Materials Abrasion Resistance Tester is designed to evaluate the wear resistance of various flooring materials, including tiles, carpets, laminates, and vinyl. By simulating real-world abrasion conditions, this instrument provides precise and repeatable measurements of surface durability, helping manufacturers, laboratories, and quality control facilities ensure compliance with international standards such as ASTM, ISO, and EN.
Application
You can use this tester to determine abrasion resistance and surface durability under controlled conditions. Typical applications include:
(1) Testing residential and commercial flooring materials such as carpets, vinyl, and laminates.
(2) Evaluating industrial flooring surfaces exposed to high foot traffic or mechanical wear.
(3) Quality control in flooring manufacturing plants.
(4) Research and development of new flooring coatings or protective treatments.
(5) Certification and compliance testing for ASTM, ISO, EN, or Taber standard requirements.
This instrument is suitable for flooring manufacturers, textile labs, R&D centers, and inspection institutions.
Standard
ASTM D3884(Abrasion Resistance of Textile Fabrics)
ISO 5470-1(Rubber or Plastics-Coated Fabrics - Abrasion Resistance)
EN 660-2(Abrasion Resistance of PVC Floor Coverings)
Taber Standard(Abrasion Testing for Coated Surfaces)
Advantages
Unmatched Precision
Equipped with a high-resolution load sensor (±0.1N accuracy) and programmable test cycles, delivering repeatable results for rigorous quality assurance.
Intuitive Operation
7-inch touchscreen control panel with multilingual support (English, Spanish, German, Chinese) and real-time data visualization for effortless test management.
Robust Engineering
Constructed with stainless steel and corrosion-resistant components, ensuring longevity even in demanding industrial environments.
Adaptive Testing Capabilities
Supports rotary, linear, and reciprocating abrasion methods to replicate diverse real-world wear scenarios, from residential to heavy industrial use.
Cost-Effective Maintenance
Modular design allows easy replacement of consumables (e.g., abrasive wheels, clamps), minimizing downtime and operational costs.
Features
Customizable Testing Parameters:
Adjustable test speed (10–120 rpm) and load pressure (1–50 N) to simulate light foot traffic to extreme industrial conditions.
Automatic cycle counter with pause/resume functionality for uninterrupted testing workflows.
Safety and Compliance:
Equipped with an emergency stop button, over-temperature protection, and CE/UL certification for safe and reliable operation.
Data Management:
Onboard memory stores over 10.000 test results, exportable via USB/Bluetooth in CSV/PDF formats for seamless data integration.
Universal Fixtures:
Interchangeable clamps accommodate tiles, carpets, laminates, and vinyl flooring (max. sample size: 300×300 mm).
Technical Parameters
| Parameter | Specification |
|---|---|
| Test Speed Range | 10–120 rpm (±1 rpm) |
| Load Capacity | 1–50 N (adjustable in 0.1N increments) |
| Sample Thickness | Up to 20 mm |
| Abrasive Wheel Diameter | 150 mm (standard Taber H-18/CS-17) |
| Power Supply | 110V/220V, 50/60Hz, 300W |
| Dimensions (L×W×H) | 600×450×800 mm |
| Weight | 85 kg |
| Operating Environment | 15–35°C, ≤85% RH (non-condensing) |
