Automatic Rain Spray Tester
Get a quote：
Whats/App: +86 156 1874 6768
Web: standard-groups.com
This instrument simulates rain sprayed horizontally onto a fabric sample vertically fixed in a stainless steel tank. A standard absorbent paper is placed against the back of the sample (weighed before and after testing). Water in the jet is sprayed through a standard nozzle to form rain, and the water jet volume can be adjusted from 600 mm (24 inches) to 2400 mm (96 inches) in 300 mm (12-inch) increments.The Rain Tester features an interactive LCD color touchscreen with preset ISO and AATCC test standards, water temperature, water jet height, and test time. A built-in water tank recovers water sprayed onto the sample and includes a heater to control the water temperature. A precision water pump automatically maintains the water jet at the set height.It cannot be modified and can be ordered with a new rain tester. We can provide a temperature-controlled water supply system, including an electronic temperature controller, mixing tank, and solenoid control valve.
Applications
The rainproof tester can test the water repellency of fabrics or composite materials under different rainwater pressures.
Standards
AATCC 35: Water Resistance: Rain Test for Fabrics
BS EN ISO 22958: Textiles – Determination of Resistance to Water Penetration – Rain Test
GB/T 23321: Textiles – Testing and Evaluation for Water Repellency
Features
Horizontal Spray System: 13 nozzles (φ0.99mm) simulate directional rainfall at 305mm from the sample.
Adjustable Water Column: 60–150 cm (standard) or 60–240 cm (extended) pressure range.
Stainless Steel Construction: Corrosion-resistant inner groove for vertical sample fixation.
Automated Replenishment: Algorithm maintains constant water level for consistent pressure.
Sample Compatibility: Fits 40mm × 285mm × 190mm material sizes (e.g., fabrics, laminates).
Safety & Compliance: Overheat protection, emergency stop, and CE certification.
Technical Parameters
| Parameter | Specification |
|---|---|
| Test Water Column | 60–150 cm (±1.5 cm) / 60–240 cm (Extended) |
| Water Temperature | 20°C ±1°C (Adjustable) |
| Control Mode | PLC + 7-inch Touchscreen |
| Nozzle Quantity/Size | 13 pcs, φ0.99 mm |
| Nozzle-to-Sample Distance | 305 mm |
| Sample Holder Size | 40 mm × 285 mm × 190 mm |
| Reservoir Capacity | 40 L (Tap/Distilled Water) |
| Heating Power | 1000 W |
| Power Supply | AC 220V ±10%, 50Hz |
| Dimensions (L×W×H) | 810 mm × 610 mm × 1450 mm |
| Net Weight | 125 kg |
