Urinary Catheter Strength Tester | ASTM ISO Testing Machine
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
The Urinary Catheter Strength Tester is designed to evaluate the physical strength and mechanical properties of urinary catheters. It provides accurate, quantitative measurement of tensile strength, elongation, and other mechanical parameters, serving as a critical tool for catheter certification, quality control, and R&D.
Application
The tester is suitable for testing urinary catheters in the following industries and products:
(1) Medical Device Manufacturing: Quality control and validation of single-use sterile urinary catheters.
(2) Research & Development: Mechanical testing of new catheter designs, wall thickness, and material properties.
(3) Certification & Regulatory Testing: Compliance testing according to national and international standards.
(4) Third-Party Testing Laboratories: Independent verification of catheter strength and performance.
(5) Educational & Training Institutions: Demonstration and training for medical device testing protocols.
Standards
The instrument is compliant with the following standard:
(1) YY 0325-2016 – Single-use Sterile Urinary Catheters, specifying requirements for mechanical and physical strength testing
(2) ISO 10555-1:2013 – Intravascular catheters — Sterile single-use catheters — Part 1: General requirements
(3) ASTM F2081-15 – Standard Test Method for Tensile Strength of Catheter Tubing
(4) EN ISO 10555-2 – Sterile single-use urinary catheters — Part 2: Materials, tensile strength, and elongation testing
Technical Parameters
| Parameter | Specification |
|---|---|
| Interface Language | Simplified Chinese / English |
| Nominal Specifications | Supports all catheter sizes |
| Load Range | 0.01–120 N |
| Accuracy | ±0.001 N |
| Loading Speed | 0–500 mm/min ±0.5 mm/min |
| Printing System | Stores 100 test records per cycle (data + deviation) |
| Net Weight | 15 kg |
| Dimensions (L×W×H) | 430 × 290 × 250 mm |
| Power Supply | AC 110–220 V, 50 Hz (auto-adaptive) |
| Power Consumption | 70 W |
| Control System | PLC + ARM programmable controller |
| Touchscreen | 7-inch K600+ core, 800×480 resolution, 65k colors |
| Sensor | High-precision force transducer |
| Force Measurement | Built-in load cell system |
| Printing Device | Onboard thermal printer |
