Laser Compression Deformation Tester
Get a quote：
Whats/App: +86 181 0160 0864
The Laser Compression Deformation Tester for sealing strips is designed for automotive sealing strips to precisely measure compression deformation and residual deformation. Using non-contact laser scanning technology, it captures linear compression curves with high accuracy and repeatability. The system evaluates elastic sealing strips throughout compression and release, generating quantitative data for quality control and R&D analysis.
Application
(1) Automotive sealing strip testing: door, window, trunk, and hood seals compression and permanent deformation evaluation.
(2) Automotive elastomer components: seals, vibration dampers, and elastic parts long-term compression performance testing.
(3) R&D and quality control: new material development, material selection, and batch consistency verification.
(4) Automotive supply chain: supplier quality inspection to ensure compliance.
(5) Environmental simulation: combined with temperature and humidity testing for deformation behavior under various conditions.
(6) Industrial rubber products: applicable to other elastic rubber profiles beyond automotive seals.
Standards
(1) GB/T 7759-2008: Determination of compression set of rubber and rubber products.
(2) GB/T 21282-2007: Compression performance testing for automotive rubber seals.
(3) QC/T 709-2007: Automotive rubber seal compression performance test specification.
(4) VW PV 3363: Determination of permanent deformation of automotive sealing strips.
(5) SMTC 3 C00003-2010: Sealing strip compression performance test.
(6)ASTM-D395
(7)JIS K6262
(8)ISO 815
Parameters
| Parameter | Specification | Description |
|---|---|---|
| Base Plate Size | 750 × 530 mm² | Width × Depth |
| Machine Height | ~500 mm | Including laser measurement device |
| Instrument Weight | ~42 kg | Easy installation and handling |
| Laser Measurement Range | 1–60 mm | Non-contact scanning |
| Measurement Accuracy | <6 µm | Precision compression measurement |
| Measurement Resolution | 0.00005–0.1 mm | High-resolution data acquisition |
| Software Platform | Windows 7 or higher | Data recording and processing |
| Data Output | MS Excel / Print | Compression-time curve and residual deformation report |
| Adjustable Measurement Time | Continuous or interval measurement | User-defined sampling time |
Features
(1) Non-contact laser measurement prevents additional compression or sample damage.
(2) Linear compression curve recording captures full compression and unloading process.
(3) High precision (<6 µm) and high resolution (up to 0.00005 mm).
(4) Automated data processing generates compression-time graphs, residual deformation analysis, and standard deviation.
(5) Multi-point measurement supports sequential or preset-time measurements.
(6) User-friendly Windows software with context help, records username, date, and test time.
(7) Compatible with MS Excel 2000 and above for reporting.
(8) Adjustable clamping device fits different sealing strip sizes.
