Seat Belt Test Dummy Manufacturer | Automotive Seatbelt Safety Testing Equipment

Get a quote:

Whats/App: +86 156 1874 6768

Web: standard-groups.com

The Crash Test Dummy for Seatbelt Testing is a high-precision anthropomorphic test device designed specifically for dynamic evaluation and development of automotive seatbelt systems. It represents a 50th percentile adult male, with physical mass distribution and body dimensions accurately modeled. Constructed from metal, fiberglass, and polyurethane materials, it realistically simulates the skeletal and muscular responses of the human body under dynamic seatbelt loading conditions.

Standards

This dummy complies with the following standards:

(1) GB 14166-2013 Motor Vehicle Occupant Restraint System Crash Test Dummy;

(2) ECE R16 Uniform Provisions for Vehicle Seatbelt and Restraint System Certification;

(3) ISO 15830 Road Vehicles – Side Impact Dummy for Restraint System Evaluation.

Parameters

Dimensional Parameters

No.Measurement ParameterDimension (mm)
1 Head Width 160 ± 5
2 Shoulder Width 465 ± 5
3 Hip Position Torso Width 120 ± 5
4 Hip Width 340 ± 5
5 Knee Center to Floor 510 ± 10
6 Hip Center to Floor 990 ± 10
7 Torso Upper Plane to Floor 1470 ± 10
8 Head Bolt Center to Floor 1600 ± 10
9 Head Top to Floor 1750 ± 10
10 T-Point Height 720 ± 5
11 P-Point Height 320 ± 5

Mass Distribution

No.ComponentMass (kg)
1 Head Assembly 4.0 ± 0.2
2 Neck Assembly 0.7 ± 0.1
3 Torso Assembly 29.7 ± 1.0
4 Thigh Assembly (L/R) 12.3 ± 0.3
5 Lower Leg Assembly 8.4 ± 0.3
6 Hip Joint 3.1 ± 0.1
7 Knee Joint Assembly 1.1 ± 0.1
8 Outer Jacket + Chest Pad 1.1 ± 0.1
9 Total Mass (including calibration) 75.5 ± 1.0

Sensor Configuration

Installation LocationSensor TypeChannels
Head Accelerometer 3
Chest Cable Displacement Sensor 1
Pelvis Cable Displacement Sensor 2

Features

(1) Accurately represents the mass distribution and body dimensions of a 50th percentile adult male;

(2) Modular design allows for quick replacement of the head, neck, torso, and leg assemblies;

(3) Metal and fiberglass skeleton with polyurethane covering provides high biomechanical fidelity and durability;

(4) Soft chest pad ensures realistic seatbelt loading simulation;

(5) Easy to operate and configure, enabling rapid setup and reliable data acquisition;

(6) Suitable for regulatory compliance and research applications.
