Cigarette Draw Resistance Tester
Get a quote：
Whats/App: +86 181 0160 0864
Web: gellowen.co.uk
The Cigarette Draw Resistance Tester is designed to measure the airflow resistance encountered by a cigarette during the smoking process. By simulating normal smoking conditions, it provides precise and objective data that supports quality control, product development, and regulatory compliance in the tobacco industry.
Application
(1) Measurement of cigarette draw resistance for quality control during manufacturing.
(2) Evaluation of airflow characteristics for research and development of new tobacco blends, filter designs, and rolling processes.
(3) Random inspections by tobacco regulatory and inspection agencies to ensure products meet relevant standards.
(4) Monitoring and controlling batch-to-batch consistency of draw resistance in production lines.
(5) Verification of filter performance and ventilation design.
(6) Comparison of different cigarette types (e.g., king-size, slim, unfiltered) for sensory quality evaluation.
(7) Assessment of cigarette draw resistance in product optimization and consumer preference studies.
Standards
(1) ISO 6565 – Cigarettes — Determination of draw resistance.
(2) CORESTA Recommended Method No. 6 – International protocol for cigarette draw resistance testing.
(3) GB/T 33029 – China national standard for cigarette draw resistance.
(4) Other applicable national standards depending on the country of manufacture or sale.
Features
(1) Objective Measurement – Provides precise, quantitative evaluation of draw resistance.
(2) Rapid Testing – Average test time of 15 seconds per cigarette.
(3) Automated Operation – Many models offer automatic clamping, testing, and data processing.
(4) Non-Destructive Testing – Test performed on unlit cigarettes without altering their structure.
(5) Real-Time Data Display – Digital output for immediate analysis and quality monitoring.
(6) Versatile Application – Suitable for production, R&D, and regulatory inspections.
Technical Parameters
| Parameter | Specification |
|---|---|
| Measuring Range | 0–10 kPa |
| Resolution | 1 Pa |
| Test Error | <1 % |
| Test Time | ~15 seconds per sample |
| Test Port Inner Diameter | 7.7 mm |
| Test Port Depth | 9 mm |
| Power Supply | AC 100–240 V, 50/60 Hz |
| Data Output | USB port for computer communication |
| Operating Environment | Room temperature, standard laboratory conditions |
Send product request
Other supplier products
 |
Large - Scale Bending Tester STD - FB2 - L | Get a quote： Whats/App: +86 181 0160 0864 Web: gellowen.co.uk TheLarge Bending Tester accurately and quickly measures factors related to curvatu... |
 |
