CE Certified High Frequency Friction Machine Factory

Get a quote:

Whats/App: +86 156 1874 6768

Web: standard-groups.com

The High Frequency Friction Machine is a reciprocating tribological testing instrument designed to study high-frequency friction, wear, and tribological behavior of metals, ceramics, and composite materials under dry or lubricated conditions. You can apply controlled loads up to 1.000 N over a maximum stroke of 25 mm while precisely controlling frequency, temperature, and test sequence via PC interface and dedicated software. The system has been validated through multi-laboratory comparisons during ASTM G133 and ASTM G181 standard development, ensuring high reliability and international recognition.

Standards

You can perform tests in accordance with:

(1) ASTM G133 – Linear Reciprocating Ball-on-Flat Sliding Wear Test

(2) ASTM G181 – Friction Test Method for Piston Rings and Cylinder Liner Materials

(3) ASTM D5706 / D5707 / D6079 – Lubrication and friction-related testing

(4) ASTM G203 / G206 – Friction, wear, and surface failure testing

(5) ISO/DIS 12156-2 – Lubricity evaluation (HFRR related)

(6) BS EN 1071-12 – Advanced ceramics friction and wear testing

(7) CEC F-06-A-96 – Diesel fuel lubricity evaluation

(8) DEF STAN 91-110/1 – Fuel lubrication performance assessment

Parameters

ParameterSpecification
Contact Type Ball-on-Flat (point contact) / Cylinder-on-Flat (line contact) / Plane contact
Optional Contact Piston ring–cylinder liner
Load Range 5–1.000 N
Loading Rate 50 N/s
Frequency Range 2–50 Hz
Maximum Stroke 25 mm
Temperature Range Ambient to 600°C
Heating Power 800 W
Temperature Sensor K-type thermocouple
Friction Force Sensor Piezoelectric
Force Measurement Range ±500 N
Stroke Sensor Magnetic induction
Linearity 0.50%
Motor 1.1 kW AC vector motor (2048 ppr encoder)
Contact Potential 50 mV DC
Software Software
Data Interface USB (high speed) / Serial (low speed)

Features

(1) Genuine sinusoidal reciprocating motion (Scotch Yoke) ensures stable, repeatable displacement.

(2) Maximum 25 mm stroke allows effective wear generation compared to short-stroke electromagnetic systems.

(3) Servo and spring combined loading provide precise load control.

(4) Optional reduction gearbox enables ultra-low-speed testing down to 0.01 Hz.

(5) Simultaneous acquisition of low-speed trend and high-speed transient data up to 50 kHz.

(6) Friction noise measurement for analysis of lubrication status and friction stability.

(7) Supports rolling-sliding, fretting, and impact fretting wear simulations.

(8) Modular accessory system enables expansion for diverse engineering tribology applications.

Accessories

Standard Ball-on-Flat Test Assembly – 6 mm / 10 mm balls

Standard Line Contact Tool – Ø6 mm × 16 mm

Optional TE 77/WEAR – Online wear monitoring system

Optional TE 77/PROFILE – In-situ profilometer

Optional Piston Ring Fixture – Adjustable curvature

Optional Inert Gas Chamber – Inert or corrosive atmosphere

Optional Cooling Module – Minimum -50°C

Consumables: Ball specimens – steel, ceramic, etc.

Consumables: Plate specimens – typical 38 × 58 × 4 mm
