Compression Tester G5
Get a quote：
Whats/App: +86 181 0160 0864
Web: gellowen.co.uk
The G5 Compression Tester is designed to simulate fingertip or other localized contact pressure on materials. It accurately measures compression hardness, compression work, and recovery properties, providing quantitative data for evaluating material tactile comfort and mechanical performance. It is suitable for testing compression characteristics of fibers, rubber, foam, footwear materials, mattresses, and soft materials used in consumer electronics.
Application
The G5 Compression Tester is suitable for:
Fibers and Textiles: Compression comfort testing of underwear, bedding, and apparel fabrics
Rubber and Foam Materials: Footwear soles, seat cushions, packaging materials
Bedding Products: Evaluation of compression and recovery of mattresses, pillows, and lumbar cushions
Consumer Electronics: Testing compression performance of touch buttons, soft housings, and cushioning pads
Medical Products: Assessment of compression characteristics of dressings, protective pads, and soft materials
Scientific Research: Studies on material compression mechanics, tactile comfort, and rebound performance
Standards
GB/T 6669-2011 — Test methods for compression properties of rubber, foam, and soft materials
ISO 3386-1/2 — Determination of compression properties of foam
ASTM D3574 — Standard test methods for flexible polyurethane foam
Technical Parameters
| Parameter | Specification |
|---|---|
| Dimensions / Weight | Tester: W170 × D220 × H460 mm / 13 kg Electronic Amplifier: W180 × D400 × H400 mm / 13 kg |
| Power Supply | AC 100V, max. power 20W |
| Measurement Environment | Temperature 20–30℃, Humidity 50–70% RH, non-condensing |
| Compression Load Testing | Differential transformer (ring-type load cell) |
| Compression Load Range | 100 gf, 200 gf, 500 gf, 1000 gf (switchable) |
| Compression Load Accuracy | ≤ ±0.5% full scale |
| Compression Deformation Measurement | Potentiometer |
| Maximum Compression Deformation | 20 mm |
| Deformation Accuracy | ≤ ±0.5% full scale |
| Compression Platen Area | 2 cm² (standard circular platen) |
| Compression Speed | Standard: 0.02 mm/sec High Sensitivity: 0.0067 mm/sec Adjustable |
| Sample Size | Square 2–10 cm |
