High Precision Torque Rheometer CE Certified
Get a quote：
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Application
1.UPVC processing performance research and material development
2. Development and processing properties of thermoplastic materials
3. Research on curing properties of crosslinking and thermosetting resins
4. Application of teaching and research
Standards
KR-803B:KR-803B Explosion-proof Torque Sensor
ASTM E2510-20:Standard Test Method for Torque Calibration or Conformance of Rheometers
IS0 11357: Plastics - Differential scanning calorimetry (applicable in thermal behavior analysis during rheological testing)
IS0 6721: Plastics - Determination of dynamic mechanical properties
ASTM D4440: Standard Test Method for Plastics - Torque Rheometer Evaluation of Processability
DIN 53014: For general torque and shear testing
ASTM D2538. ASTM D2230: Specific to PVC processing behavior analysis
Features
With modular design and ready-to-use function: the host is the control center, with the function of driving and controlling the measurement unit; Controlled auxilaries, such as mixing units and extrusion units, are intelligent application-specific measurement units that transmit measurement data to the host via a bus system. It can be equipped with various auxiliary machines to complete laboratory simulation experiments for different purposes.
Parameters
| Feature/Specification | Details |
|---|---|
| Motor Power (Panasonic Motor, Controller) | 3.0 kW |
| Motor Speed | 2000 r/min |
| Reduction Ratio (Hubei Kefeng Reducer) | 15:1 |
| Speed Range | 0.1 - 150 rpm |
| Speed Control Accuracy | ±0.2% F.S. |
| Torque Measurement Range | 0 - 200 Nm (Rated Torque 300 Nm) |
| Torque Measurement Accuracy | ±0.3% F.S. |
| Melt Pressure Measurement Range | 0.1 - 100 MPa |
| Pressure Measurement Accuracy | ±0.3% F.S. |
| Temperature Control Range (Five-way Temperature Control) | Room Temperature - 350℃ |
| Temperature Control Accuracy | ±0.5℃ |
| Graphic Display | Speed, Torque, Temperature, Pressure |
| Voltage | AC 380 V, 7.5 kW |
Accessories
(1)Die and Mold Sets
Plate molds, cap molds, or cavity molds depending on the material type.
Used to shape the sample and control geometry during testing.
(2)Mixing and Dispersion Tools
Rotor/stator assemblies for mixing compounds before testing.
Helps ensure uniformity in viscous or rubber compounds.
(3)Temperature Control Units
Heating or cooling plates for precise thermal conditions.
Includes thermostats, heating jackets, or oil baths.
(4)Clamps and Sample Holders
To securely hold rubber, plastic, or composite samples during rotation.
Some rheometers include interchangeable clamps for different sample sizes.
(5)Torque Sensors and Load Cells
High-precision sensors to measure torque accurately.
Can be integrated or modular for replacements.
(6)Protective Covers and Safety Guards
Shields against hot surfaces or spinning parts for operator safety.
(7)Data Acquisition Systems / Software
Computer interface, software for recording torque vs. time/temperature curves.
Some include automated data analysis modules.
(8)Optional Add-ons
Oxygen or inert gas chambers for testing materials sensitive to oxidation.
Humidity chambers for testing moisture-sensitive materials.
High-speed rotors or specialized mixing blades for advanced compounding studies.
