Airbag-Type Contact Pressure Tester
Get a quote：
Whats/App: +86 181 0160 0864
Web: gellowen.co.uk
The Airbag-Type Contact Pressure Tester is designed to evaluate contact pressure between garments, hosiery, wearable devices, and the human body. It allows you to accurately assess wearing comfort, garment functionality, and user experience for clothing design, textile research, sock development, and ergonomic studies.
Application
You use this tester to measure contact pressure in:
Functional garments such as compression wear and sportswear
Medical and therapeutic hosiery (e.g., pressure socks and sleeves)
Wearable devices that interact with the human body
Ergonomic studies of clothing fit and comfort
Textile material R&D for clothing and accessories
Standards
The Airbag-Type Contact Pressure Tester complies with the following standards:
(1) FZ/T 73031-2009 Pressure socks
(2) DD ENV 12718-2001 Medical compression knitted fabrics
(3) CEN/TR 15831 Test methods for medical sock compression performance
(4) RAL-GZ 387/1 Pressure testing for compression hosiery products
(5) RAL-GZ 387/2 Pressure performance testing of medical pressure textiles (e.g., socks, sleeves)
Parameters
| Item | Specification |
|---|---|
| Measurement Points | 1 |
| Force Sensor | Ultra-soft, non-stretch airbag, thickness <1 mm; fully contacts the human body and flexible fabrics to detect micro pressure changes accurately |
| Measurement Range | 0–38.00 kPa ±0.1 kPa |
| Measurement Accuracy (23℃) | ±0.1 kPa |
| Measurement Interval | Minimum 100 ms, high repeatability, minimally affected by temperature |
| Display & Control | Large color touchscreen, Chinese/English interface |
| Maximum Airbag Pressure | ≤100 kPa |
| Operating Environment | 0–45℃, relative humidity 25–85% |
| Power Supply | AC 220V, 50Hz, 1000W |
| Instrument Dimensions (W×D×H) | 400×450×1500 mm |
| Instrument Weight | 150 kg |
Send product request
