Fabric Insulation Performance Testing Machine Wholesale Supplier
Get a quote：
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Features
Dual-Sensor Accuracy: Simultaneous measurement of sample plate and heating block temperatures with ±0.1% precision.
Variable Speed Control: Adjustable brass cylinder velocity (1–60 mm/s) for dynamic thermal impact tests.
Bi-Directional Safety: Automatic polyethylene shield deployment prevents operator exposure.
Wide Temperature Range: Suitable for extreme thermal condition simulation (-5°C to 180°C).
Global Compliance: Pre-configured GB/T and BS test sequences facilitate international certification.
Compact Footprint: Benchtop design fits QC labs and R&D facilities.
High-Speed Data Logging: 100 kHz sampling captures transient thermal events accurately.
Parameters
| Parameter | Specification |
|---|---|
| Sample Size | Ø70 mm (circular) |
| Temperature Range | -5°C – 180°C (±0.5°C accuracy) |
| Temperature Resolution | 0.1°C |
| Brass Cylinder | 3.000 ±10 g, dual-zone temperature sensing |
| Cylinder Velocity | 1–60 mm/s (adjustable) |
| Safety Shield Deployment | 80 mm/s automatic at 60°C threshold |
| Data Sampling Rate | 100.000 samples/second |
| Power Supply | AC 220 V ±10%, 50 Hz, 600 W |
| Dimensions (L×W×H) | 540 × 380 × 500 mm |
| Weight | 40 kg (net) |
| Operating Environment | 10°C–40°C, <85% RH |
Accessories
(1) Brass Impact Assembly: Tapered cylinder (3.000 ±10 g) with dual K-type thermocouples
(2) Sample Holder Kit: Vacuum suction specimen platform (Ø70 mm) with non-stick PTFE coating
(3) Safety System: Motorized polyethylene shield (200 × 250 × 15 mm) and emergency stop interlock
(4) Calibration Bundle: NIST-traceable temperature standard and velocity verification gauge
(5) Operator Kit & Software: Insulated tweezers, sample cutting die, ThermalGuard Pro software with automated reporting and 21 CFR Part 11-compliant audit trail
Test Procedures
(1) Prepare the sample by cutting it to Ø70 mm and placing it on the vacuum specimen platform.
(2) Verify cylinder weight and ensure dual thermocouples are properly positioned.
(3) Set the desired temperature range and cylinder velocity on the touchscreen PLC.
(4) Initiate the test; the brass cylinder impacts the sample while data is collected at 100 kHz.
(5) Monitor thermal readings and ensure safety shield is in position.
(6) Upon completion, export data to CSV or generate automated reports using ThermalGuard Pro.
