Car Seat Belt Locking Performance Tester | ISO & ECE R16 Automotive Safety Testing Machine Factory Supplier
Get a quote：
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Features
1、Advanced PLC Control System
Ensures stable test execution, automated operation, and precise data processing.
2、User-Friendly Interface
Equipped with a color touchscreen interface supporting Chinese/English switching, improving usability for global operators.
3、Multi-Angle Mounting Design
Supports retractor mounting at 45°, 90°, 135°, and 180° to simulate various vehicle installation conditions.
4、High-Precision Acceleration Simulation
Acceleration range of 0.2–1.5 g with fine adjustment steps ≤ 0.05 g for accurate test condition configuration.
5、High-Accuracy Sensor System
Acceleration accuracy < 0.01 g; locking distance accuracy ≤ 0.01 mm ensures trustworthy measurement results.
6、Fast Emergency Locking Simulation
Achieves 2.94 m/s within 50 ms, replicating real-world emergency braking and impact scenarios.
7、Industrial-Grade Mechanical Structure
Stable, durable, and designed for long-term continuous operation in professional laboratories.
Parameters
| Parameter | Specification |
|---|---|
| Control System | PLC automation + data processing |
| Operation Interface | Color touchscreen (Chinese/English) |
| Emergency Lock Test Speed | 2.94 m/s within 50 ms |
| Mounting Angle Options | 45°, 90°, 135°, 180° |
| Acceleration Adjustment Range | 0.2–1.5 g |
| Acceleration Adjustment Step | ≤ 0.05 g |
| Maximum Sled Displacement | 100 mm |
| Inductive Acceleration Range | ≥ 0.2–2.5 g |
| Acceleration Measurement Accuracy | < 0.01 g |
| Acceleration Repeatability | ≤ ±0.01 g |
| Acceleration Overshoot | < 10% of set value |
| Locking Distance Accuracy | ≤ ±0.01 mm |
Accessories
1、Seat belt retractor mounting fixtures
2、Adjustable installation frame
3、Acceleration calibration module
4、High-precision displacement sensors
5、Data acquisition & analysis software
6、Industrial computer with data storage
7、Protective covers and anti-vibration base
Test Procedures
1、Install the seat belt retractor at the required mounting angle.
2、Set acceleration, movement, and locking parameters via touchscreen.
3、Start the test; the system automatically executes the acceleration and locking procedure.
4、View, store, or export test data in CSV format for reporting and analysis.
Maintenance
1、Inspect mechanical parts regularly for wear or loosened components.
2、Calibrate acceleration and displacement sensors periodically.
3、Ensure the electrical cabinet remains clean and dry.
4、Check connectors and cables for secure contact.
5、Perform system software updates when available.
6、Lubricate moving components as required.
