GC Centrifugal Pump
Product name:GC Centrifugal Pump
Model:GC Centrifugal Pump
Application:GC type pump is horizontal, single suction multistage centrifugal pumps
Product overview
GC boiler feed multistage centrifugal pump Overview:
GC type pump is horizontal, single suction multistage centrifugal pumps. With high efficiency, wide range of performance, safe and stable operation, low noise, long life, easy installation and maintenance. Other liquids used for conveying water or physical and chemical properties similar to water.
Secretary of the products designed and optimized by computer processing, the company has strong technical force, rich production experience and improve the detection means, so as to ensure stable and reliable product quality.
GC horizontal multi-stage centrifugal pump range of parameters:
Traffic: 5-55m3 / h;
Head: 46-301m;
Power: 3-75KW;
Speed: 2950r / min;
Diameter: φ40-φ100;
Temperature range: ≤110 ℃;
Working pressure: ≤2.7Mpa.
GC boiler feed water pump Model Description:
2.5 GC 6 × 5
2.5 - suction diameter (inches)
GC - sub-type boiler feed pump
6 - reduced to 1/10 of the pump specific speed
5 - impeller series
"5" - said the series.
GC-type horizontal multistage centrifugal pump features:
1, hydraulic model of advanced, high efficiency, wide range of performance.
2, the pump runs smoothly, low noise.
3. Seal with soft packing seal, safe, reliable, simple structure, convenient maintenance.
| TYPE | FOLW Q |
RANGE H |
Rotational speed n |
Shaft power Pa |
Electric motor | Efficiency n |
Steam eclipse amount | Impeller diameter | Imported caliber | Outlet diameter | weight | ||
| m3/h | L/s | m | r/min | kw | POWER/kw | type | % | m | mm | mm | mm | kg | |
| 1½GC-5*2 | 6 | 1.66 | 46 | 2950 | 2 | 3 | 38 | 3.6 | 0 | 0 | 70 | ||
| 1½GC-5*3 | 6 | 1.66 | 69 | 2950 | 3 | 4 | 38 | 3.6 | 0 | 0 | 76 | ||
| 1½GC-5*4 | 6 | 1.66 | 92 | 2950 | 4 | 6 | 38 | 3.6 | 0 | 0 | 89 | ||
| 1½GC-5*5 | 6 | 1.66 | 115 | 2950 | 5 | 8 | 38 | 3.6 | 0 | 0 | 98 | ||
| 1½GC-5*6 | 6 | 1.66 | 138 | 2950 | 6 | 8 | 38 | 3.6 | 0 | 0 | 107 | ||
| 1½GC-5*7 | 6 | 1.66 | 161 | 2950 | 7 | 8 | 38 | 3.6 | 0 | 0 | 116 | ||
| 1½GC-5*8 | 6 | 1.66 | 184 | 2950 | 8 | 11 | 38 | 3.6 | 0 | 0 | 125 | ||
| 1½GC-5*9 | 6 | 1.66 | 207 | 2950 | 9 | 11 | 38 | 3.6 | 0 | 0 | 134 | ||
| 2GC-5*2 | 10 | 2.8 | 64 | 2950 | 5.5 | 6 | 39.6 | 4.6 | 0 | 0 | 140 | ||
| 2GC-5*3 | 10 | 2.8 | 96 | 2950 | 7.5 | 8 | 39.6 | 4.6 | 0 | 0 | 163 | ||
| 2GC-5*4 | 10 | 2.8 | 128 | 2950 | 11 | 11 | 39.6 | 4.6 | 0 | 0 | 178 | ||
| 2GC-5*5 | 10 | 2.8 | 160 | 2950 | 15 | 15 | 39.6 | 4.6 | 0 | 0 | 193 | ||
| 2GC-5*6 | 10 | 2.8 | 192 | 2950 | 15 | 15 | 39.6 | 4.6 | 0 | 0 | 206 | ||
| 2GC-5*7 | 10 | 2.8 | 224 | 2950 | 18.5 | 18 | 39.6 | 4.6 | 0 | 0 | 223 | ||
| 2GC-5*8 | 10 | 2.8 | 256 | 2950 | 17.6 | 22 | 39.6 | 4.6 | 0 | 0 | 238 | ||
| 2GC-5*9 | 10 | 2.8 | 288 | 2950 | 19.8 | 22 | 39.6 | 4.6 | 0 | 0 | 253 | ||
| 2½GC-6*2 | 15 20 |
4.2 5.6 |
62 54 |
2950 | 5.8 6.2 |
8 | 43.7 47.4 |
4.9 5.2 |
0 | 0 | 149 | ||
| 2½GC-6*3 | 15 20 |
4.2 5.6 |
93 81 |
2950 | 8.7 9.3 |
11 | 43.7 47.4 |
4.9 5.2 |
0 | 0 | 172 | ||
| 2½GC-6*4 | 15 20 |
4.2 5.6 |
124 108 |
2950 | 11.6 12.4 |
15 | 43.7 47.4 |
4.9 5.2 |
0 | 0 | 187 | ||
| 2½GC-6*5 | 15 20 |
4.2 5.6 |
155 135 |
2950 | 14.5 15.6 |
18 | 43.7 47.4 |
4.9 5.2 |
0 | 0 | 202 | ||
