Cast Iron Butterfly Vavle
Mainpartsandmaterials
|
Partsname |
material |
|
Body、Bonnet |
Castiron |
|
Disc |
Stainlesssteel |
|
Stem |
Stainlesssteel |
|
SeatRing |
NBR/EPDM |
standards
|
DesignandManufacture |
Facetoface |
Flangeend |
Inspection |
|
KSB2813 |
KSB2306 |
KSB1511 |
KSB2304 |
Test
|
Nominalpressure |
Strengthtesting |
Enclosetesting |
|
10K |
Dimensions
|
DN(mm) |
50 |
65 |
80 |
IOO |
125 |
150 |
200 |
250 |
300 |
350 |
|
L |
43 |
46 |
46 |
52 |
56 |
56 |
60 |
68 |
78 |
78 |
|
Z×φd |
Z×φ19 |
Z×φ19 |
Z×φl9 |
Z×φI9 |
Z×φ23 |
Z×φ23 |
Z×φ23 |
Z×φ25 |
Z×φ25 |
Z×φ25 |
|
DO |
120 |
140 |
150 |
175 |
210 |
240 |
290 |
355 |
400 |
445 |
