Catheter Guidewire Friction Tester
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Application
This tester is suitable for a wide range of medical devices and scenarios, including:
(1) Vascular catheters – assessing friction during navigation through blood vessels.
(2) Guidewires – evaluating smoothness and performance in different sizes and coatings.
(3) Interventional cardiology devices – testing guidewire-catheter interaction for stent delivery or balloon angioplasty.
(4) Neurovascular procedures – verifying low-friction performance for delicate cerebral interventions.
(5) Peripheral vascular interventions – assessing devices for minimally invasive surgery.
(6) R&D and quality control – optimizing material, coating, and design for improved surgical outcomes.
Standards
The instrument is designed to comply with the following standards:
(1) YY/T 1536-2017: Cardiovascular guidewire test method (China)
(2) ISO 11070: Sterile single-use intravascular catheters – Performance testing
Optional international standards for extended compliance:
(3) ISO 10555-1: Sterile single-use intravascular catheters – General requirements
(4) ASTM F2084: Guidewire mechanical performance testing
Features
(1) Measures friction force accurately between catheters and guidewires.
(2) High-precision force and displacement sensors capture real-time data.
(3) Stepless adjustable test speed to simulate different clinical scenarios.
(4) Adjustable chuck size accommodates a variety of catheter and guidewire diameters.
(5) Compact design suitable for laboratory and R&D use.
(6) Data acquisition system records force-displacement curves for analysis.
Parameters
| Parameter | Specification |
|---|---|
| Test range | 0 – 500 N (optional: 50 N, 100 N, 200 N, 1000 N) |
| Measurement accuracy | 0.5 level |
| Travel | 800 mm |
| Test speed | 0.5 – 500 mm/min, stepless transmission |
| Displacement accuracy | 0.01 mm |
| Sample quantity | 1 piece |
| Chuck size | 0 – 30 mm |
| Dimensions (L × W × H) | 450 × 500 × 1500 mm |
| Weight | 75 kg |
Accessories
(1) Test fixture with adjustable chucks – 1 set
(2) Force sensor – integrated
(3) Displacement sensor – integrated
(4) Control and data acquisition system – 1 set
(5) Operation manual – 1 set
(6) Optional adapters for different catheter or guidewire diameters
