Carton drop tester

Product introduction

  It is mainly used to simulate the impact of the drop impact on the packaging during

transportation and loading and unloading to identify the impact strength of the packaging

and the rationality of the packaging design. The vertical impact test of the transport package

by free drop can be freely selected in advance of the three states of surface, edge and Angle

drop test, the drop height can be preset, when the test piece rises to the preset height, it can

be automatically positioned, and the drop height can be preset. The release mechanism is free,

flexible and reliable, ensuring that the specimen is not affected by any external force during

the release moment and free fall, thus ensuring the required drop state of the specimen. Strong

structure scientific and reasonable, safe and reliable use.

Meet the standard

  GB/T4857.5, 1S02248, etc.

Technical parameter

  1. Drop height: 300mm——1500mm(adjustable)

  2. Larger sample weight: 70kg

  3. Larger sample size: 800mmx800mmx800mm

  4. Impact panel size: 1700mmx1200mmx14mm

  5. Motor power: 1.85KW

  6. Overall size: 1700mm(L)x1200mm(W)x2350mm(H)

  7: Net weight: about 600kg

  8: Power supply: AC 380V 50Hz
