Metallic Cables and Wire Ropes Mechanical Property Testing Machine
Standard
- YY/T 0812-2010 (China): Specifies mechanical testing protocols for metal cables/cables used in fracture fixation, including fatigue strength and load-to-failure requirements.
- ASTM F2180-19 (International): Defines methodologies for evaluating the dynamic fatigue performance of orthopedic cable systems under cyclic loading.
- ISO 12177-3: Additional compliance for tension-tension fatigue testing of surgical cables.
Product Advantages
- Multi-Axial Loading: Simultaneous tension/torsion control replicates in vivo stress patterns (5Hz fatigue cycles).
- High-Cycle Endurance: 1,000,000-cycle capacity with ±0.05% load accuracy at 5Hz operation.
- Biorelevant Simulation: 37±1°C saline bath with protein skimmer for in vitro corrosion testing.
- Smart Fixturing: Self-centering clamps accommodate cables (1.0–5.0 mm diameter) and cable systems.
- AI-Powered Analytics: Machine learning identifies fatigue initiation sites in real-time.
- Regulatory Compliance: Pre-loaded YY/T 0812/ASTM F2180 protocols with automated reporting.
Product Features
- Electromagnetic Servo Actuator: 10 kN tensile/5 Nm torsional capacity with programmable load ratios (R=0.1–10).
- Dynamic Load Control: 0.1–30 Hz frequency range with sine/square/random waveforms.
- Thermal-Mechanical Chamber: 37±0.5°C recirculating saline bath with anti-evaporation design.
- High-Resolution Imaging: Built-in 5MP camera system for fretting/corrosion analysis.
- Safety Suite: Emergency stop, overload clutches, and leak detection system.
- Modular Design: Dual-station configuration enables simultaneous specimen testing.
Technical Parameters
| Parameter | Specification |
|---|---|
| Max. Tensile Load | ±10,000 N (0.01 N resolution) |
| Max. Torsional Moment | ±5 Nm (0.001 Nm resolution) |
| Frequency Range | 0.1–30 Hz (0.01 Hz increments) |
| Load Ratio (R) | 0.1–10 (adjustable) |
| Cable Diameter Range | 1.0–5.0 mm (0.01 mm resolution) |
| Saline Bath Temperature | 37±0.5°C (PT1000 sensor) |
| Data Sampling Rate | 10 kHz (synchronized across 8 channels) |
| Power Requirements | 220V/110V ±10%, 50/60Hz, 1,800W |
| Dimensions (W×D×H) | 600 × 500 × 800 mm |
| Weight | 90 kg (net) / 105 kg (with bath) |
| Noise Level | <55 dB (A-weighted) |
Accessories
- Cable Fixture Kit:
- Self-centering clamps (1.0–5.0 mm cable compatibility)
- Torsion adapters for multi-strand cables
- Thermal-Mechanical Bath:
- 20L capacity with recirculating pump
- Corrosion-resistant titanium interior
- CableTest Pro Software:
- Automated S-N curve generation and fatigue limit calculation
- 21 CFR Part 11-compliant audit trail with blockchain timestamping
- Remote monitoring via iOS/Android app
- Operator Kit:
- Calibrated micrometer set (0.01–1.00 mm)
- Cable alignment jigs (ASTM F2180 compliant)
- Calibration Bundle:
- NIST-traceable force/torque calibration weights
- LVDT verification tool
- Safety Kit:
- Leak detection system
- Acoustic enclosure with 25 dB noise reduction
