Liquid Spontaneous ignition point tester

Product Description

complies with GB/T 21860-2008 “Test Method for Autoignition Temperature of Liquid Chemicals” and ASTM E “Test Method for Autoignition Temperature of Liquid Chemicals” (English version).

Standards

GB/T 21860-2008

ASTM E659-78 (2005)

Product Features

1) Adopting embedded processor and Windows CE operating system.

2) 8-inch LCD touch screen, real-time display of the test status.

3) Integration of high temperature insulation technology, temperature control and precision detection technology.

4) Adopting electric heating furnace, with fast heating speed.

5) Furnace cavity is made of adiabatic vacuum ceramic fiber with good heat insulation effect.

6) Adopting thermocouple sensor for fast and accurate response to temperature change.

7) Equipped with automatic intelligent sampling module and maintenance-free automatic cleaning function.

8) The test process is fully automated, without human intervention, with animated image demonstration of the experimental process and automatic report generation.

9) Equipped with temperature and humidity module, which can monitor the temperature, humidity and atmospheric pressure of the test environment.

Technical Parameters

Operating environment

(5 to 40)°C, <85% RH

Test object

Liquid

Temperature control range

Room temperature to 650 °C

Temperature control accuracy

±1 °C up to 350 °C; ±2 °C above 350 °C

Temperature measurement range

Room temperature to 800 °C

Temperature measurement resolution

0.1 °C

Temperature measurement accuracy

±2.5 °C up to 300 °C; ±(0.75% of reading) above 300 °C

Ambient atmospheric pressure measurement range

(60 to 110)kPa

Ambient atmospheric pressure measurement accuracy

±0.5 kPa
