Cylindrical Battery In-Situ Volume Swelling Testing System

Cylindrical Battery In-Situ Volume Swelling Testing System
  • Cylindrical Battery In-Situ Volume Swelling Testing System
Produced by: Qinsun Instruments Co., LTD

All supplier products
Send product request

Standard

  • UL 1642: Standard for Lithium Batteries
  • IEC 62660-2: Secondary Lithium-Ion Cells – Part 2: Reliability and Abuse Testing
  • ASTM E83: Standard Test Method for Verification of Linear Displacement Measuring Systems
  • ISO 12417-1: Mechanical Testing of Metals – Dilation Test
  • CE Certification(Conformité Européenne)

Product Advantages

  1. Sub-Micron Precision
    • 0.05 μm Resolution: Tracks nanoscale volume changes during rapid charge/discharge cycles.
    • Laser-Based Sensors: Non-contact measurement eliminates mechanical interference.
  2. Multi-Environment Testing
    • -20°C to 150°C Chamber: Simulates extreme climates and thermal abuse scenarios.
    • Pressure Cycling: 0–30 bar dynamic loading for fatigue testing.
  3. Real-Time 3D Imaging
    • Structured Light Scanner: Generates volumetric strain maps at 5 fps.
    • AI-Powered Deformation Analysis: Quantifies anisotropic swelling in cylindrical cells.
  4. High-Throughput Design
    • 4-Channel Parallel Testing: Monitor 4 batteries simultaneously under identical/custom protocols.
    • Auto-Sequence Programming: 50+ preloaded test profiles (fast charging, overcharge, etc.).
  5. Smart Data Integration
    • API Connectivity: Syncs with EIS, thermal cameras, and gas analyzers for holistic diagnostics.
    • Cloud-Based AI: Predicts cycle life based on expansion-voltage coupling.

Product Features

  • Non-Destructive Testing (NDT): Preserves sample integrity with <0.5 N contact force.
  • Laser-Guided Alignment: Ensures precise battery positioning (±2 μm accuracy).
  • Dynamic Strain Calibration: Auto-corrects for thermal drift during long-term testing.
  • Emergency Shutoff: Dual redundant safety circuits with E-stop button.
  • Glovebox Compatibility: Oxygen/moisture levels <0.1 ppm for sensitive chemistries.

Technical Parameters

ParameterSpecification
Displacement Range ±1 mm (linear), ±0.5° (angular)
Accuracy ±0.1 μm (linear), ±0.01° (angular)
Temperature Range -20°C to 150°C (2°C/min ramp rate)
Data Acquisition Rate 5,000 points/second/channel
Power Supply 100-240V AC, 50/60Hz (universal adapter)
Dimensions 600mm (W) × 500mm (D) × 1,000mm (H)
Weight 150 kg (net) / 180 kg (gross)

Accessories Included

  1. Testing Kit:
    • 4x non-magnetic battery holders (18650, 21700 formats).
    • Disposable strain gauges (50 pack).
  2. Software Suite:
    • License key forSwellVision Pro(Windows/Linux).
    • 6-month free access to cloud-based FEA tools.
  3. Calibration & Safety:
    • NIST-traceable displacement standard (500 μm, 1 mm).
    • Explosion-proof gloves (Class 00, 3 pairs).
  4. Environmental Control:
    • Gas purification cartridge (99.999% inert atmosphere).
    • Humidity sensor with data logging.
  5. Documentation:
    • Multilingual quick-start guide (printed + digital).
    • Compliance certificates for UL/IEC/ASTM standards.
