ASTM G155 Test Chamber
Features and Benefits
1.ASTM G155 test chamberadopts xenon arc lamp as light source, producinghigh intensity and stable light, posing good simulation of natural sunlight. The radiation energy can be set and automatically controlled directly through the controller (340nm, 420nm, 300nm~400nm).
2. ASTM G155 test chambercan be used to test a variety of materials, including plastics, rubber materials, coatings and coatings, textiles and other fields.
3.Precise temperature and humidity controlin ASTM G155 test chamber: Equipped with heating and cooling systems ranging from ambientto 100 ° C, the temperature of the workroomand blackboard can be directly set and automatically controlled.Humidity range is 50% to 98%RH.
4.ASTM G155 test chamberis equipped with a spray system to simulate the effects of dew or rain.
Specifications
Model |
STD XL-S-750 |
STD XL-S-500 |
Internal Dimension (mm) |
950*950*850 mm |
500*600*700 mm |
Overall Dimension (mm) |
1400*1400*1950 mm |
1000*1140*1920 mm |
Specimen Holder Size(mm) |
95*200 |
/ |
Specimen Capacity |
42pcs |
/ |
Chamber Type |
Rotating Holder |
Flat shelf |
Irradiation Source |
1 piece of 4500w water-cooled xenon arc lamp |
|
Irradiance Range |
35~150 W/㎡ |
|
Bandwidth Measurement |
300nm~400nm (340nm or 420nm) |
|
Chamber Temperature Range |
Ambient ～ 100 ℃ ±2℃ |
|
Black Panel Temperature |
BPT 35 ～ 85 ℃ ±2℃ |
|
Humidity Range |
50% ~ 98% RH |
|
Humidity Deviation |
± 5% RH |
|
Water Spray Cycle |
1~9999H59M (Adjustable) |
|
Water supply system |
Automatic water supply, Water purification system |
|
Radiometer |
UV Radiometer, Tolerance: ±5% |
|
Cooling System |
Mechanical compression refrigeration system |
|
