Safety Helmets Acceleration Impact & Penetration Tester
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Standard
GB/T 2812: Safety Helmets (China National Standard)
Equivalent Compliance: ISO 6220-1 (Industrial Safety Helmets – Impact Absorption)
CE Certification(Conformité Européenne)
Product Advantages
Dual-Testing Capability
Impact & Penetration Modes: Simultaneously validates helmet shells against blunt force and sharp object threats.
GB/T 2812 Compliance: Meets 1.000N impact resistance and 5kg penetrator requirements.
Ultra-High-Speed Data Acquisition
20.000N Force Sensor: Captures impact spikes at 5.000Hz for millisecond-precision analysis.
0.1mm Deformation Resolution: Detects micro-fractures before catastrophic failure.
Industrial-Grade Durability
500kg Reinforced Concrete Base: Eliminates vibration during 4.2m drop tests.
Stainless Steel Penetrator: Corrosion-resistant for humid/outdoor lab environments.
User-Centric Design
7” Touchscreen HMI: Preloaded GB/T 2812 test sequences with real-time acceleration graphs.
Quick-Release Helmet Clamp: Swaps samples in seconds for high-throughput labs.
Safety First
Dual Safety Interlocks: Prevents accidental activation during helmet positioning.
Overload Protection: Auto-shutdown at 2.200N to protect sensors.
Product Features
Motorized Lifting System: 0–4.2m adjustable height with laser-guided positioning.
Modular Test Fixtures: Accommodates vented, full-brim, and custom helmet designs.
Dynamic Force Feedback: Triaxial accelerometers (10.000Hz sampling) map impact forces.
Self-Calibrating System: Auto-tare and linearity checks before each test.
Rust-Resistant Frame: 304 stainless steel construction with epoxy coating.
Accessories Included
Testing Kit:
2x Universal Helmet Clamps (adjustable for 50–65 cm heads).
5x Calibration Grade Impact Hammers (5kg ±0.1kg).
Penetration Kit:
1x 3kg Stainless Steel Penetrator (ISO 6220-1 compliant).
1x Anti-Splatter Shield (PC, 6mm thickness).
Software Suite:
License key forImpactTest Pro(Windows/Linux).
1-year free access to cloud-based impact analysis tools.
Calibration & Safety:
NIST-traceable force gauge.
2x Safety Glasses (EN 166 rated) + 1x Face Shield.
Maintenance Kit:
Spare accelerometers and load cells.
Machine cleaning solution (non-corrosive).
Documentation:
Multilingual quick-start guide (printed + digital).
Compliance certificates for GB/ISO standards.
Technical Parameters (Impact Test)
| Parameter | Specification |
|---|---|
| Base Structure | Reinforced concrete, ≥500kg mass |
| Impact Hammer | 5.0kg ±0.1kg, 50mm ±1mm hemispherical stainless steel head |
| Drop Height | 1.000mm ±5mm (adjustable) |
| Force Sensor | 0–20.000N range, 5kHz min frequency response |
| Accelerometer | ±500g range, 10.000Hz sampling |
| Data Acquisition | 16-bit resolution, 100.000Hz max sampling |
| Machine Height | 4.200mm (total) |
| Power Supply | 380V AC, 3-phase (50/60Hz) |
| Dimensions | 1.200mm (W) × 1.000mm (D) × 4.500mm (H) |
| Weight | 850 kg (net) |
