Safety Helmets Against Molten Metal Splashing Tester
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Standard
GB/T 2812-XXXX: Safety Helmets – Test Methods for Molten Metal Resistance (Draft Standard)
GB 2811-2019: Head Protection – General Technical Requirements
Equivalent Compliance: ISO 13982-2 (Protective Clothing – Resistance to Molten Metal Splash)
CE Certification(Conformité Européenne)
Product Advantages
Extreme Temperature Validation
1.800°C Max Capacity: Simulates industrial foundry environments per GB/T 2812.
1400°C ±20°C Precision: Ensures repeatable testing for EN/ISO certifications.
Precision Engineering
225mm ±5mm Pour Height: Replicates real-world splatter patterns with 100mm adjustability.
150g ±10g Iron Specimen: Meets 93% Fe-content requirements for metallurgical accuracy.
Safety First
Dual Cooling Systems: Water-cooled control panel + forced-air test chamber.
Splash Guard: High-temperature ceramic shield protects operators during testing.
User-Centric Design
7” Touchscreen HMI: Preloaded GB/T 2812 test sequences with real-time thermal imaging.
Quick-Release Crucible: Swaps specimens in seconds for high-throughput labs.
Industrial Durability
Refractory Lining: Test chamber withstands 1.800°C cyclic exposure.
304 Stainless Steel Frame: Corrosion-resistant for harsh industrial environments.
Product Features
Motorized Lift System: 0–300mm adjustable crucible height with laser-guided positioning.
Modular Head Assembly: Fits adult, child, and custom helmet sizes (50–65 cm circumference).
Dynamic Temperature Control: PID-regulated furnace with ±10°C stability.
Self-Calibrating System: Auto-tare and thermal uniformity checks before each test.
Rust-Resistant Frame: 304 stainless steel construction with ceramic-coated panels.
Accessories Included
Testing Kit:
2x Refractory Crucibles (graphite, 150g capacity).
5x Calibration Grade Thermocouples (Type K, 0–1.800°C).
Software Suite:
License key forThermalTest Pro(Windows/Linux).
1-year free access to cloud-based thermal analysis tools.
Safety Gear:
2x Heat-Resistant Gloves (EN 407 rated, 500°C).
1x Face Shield (ceramic coating, 1.800°C rated).
Maintenance Kit:
Spare refractory bricks and heating elements.
Machine cleaning solution (non-corrosive).
Documentation:
Multilingual quick-start guide (printed + digital).
Compliance certificates for GB/ISO standards.
Technical Parameters
| Parameter | Specification |
|---|---|
| Pour Height | 225mm ±5mm (adjustable 100mm range) |
| Max Temperature | 1.800°C (furnace capacity) |
| Standard Temperature | 1.400°C ±20°C |
| Molten Metal Specimen | 150g ±10g iron (Fe ≥93%) |
| Cooling System | Water-cooled control panel + forced-air chamber |
| Power Supply | 380V AC, 3-phase, 25kW |
| Dimensions | 1.250mm (W) × 750mm (D) × 1.350mm (H) |
| Weight | 450 kg (net) |
