Rattle tester
Bell Rattle Toy Tester：
Also known as:
Sound-emitting toy tester
Toy test template AB
Anti-choking test device
Simulates children's oral cavity capacity to detect potential choking hazards from toys or accessories.
Compliance Standards & Specifications：
| Specification | Elliptical Tester | Circular Tester |
|---|---|---|
| Standards | US: 16CFR 1510 / ASTM F 963 4.6.2 EU: EN71-1998 8.16 China: GB6675-2003 A.5.3 |
US: 16CFR 1510 / ASTM F 963 4.6.2 EU: EN71-1998 8.16 China: GB6675-2003 A.5.3 |
| Material | Aluminum Alloy | Aluminum Alloy |
| Dimensions | 80×65×30mm (Ellipse) | 72.6×72.6×30mm (Circle) |
| Weight | 320g | 320g |
Test Procedure & Criteria：
Testing Methodology:
1. Secure the elliptical tester with clamps ensuring vertical alignment
2. Position the toy in the most probable insertion orientation
3. Apply only gravitational force during testing
4. Observe complete penetration depth
5. Repeat for spherical/circular-ended toys using circular tester
Evaluation Criteria:
- Toys shall NOT fully penetrate elliptical tester
- Spherical/circular-ended toys shall NOT fully penetrate circular tester
- Acceptable partial penetration ≤ 50% of total depth
Special Cases:
- For ball-shaped components: Perform 3 consecutive tests
- Record maximum penetration depth for each orientation
Send product request
