Scrub Abrasion Tester
T107 Scrubbing Tester, It is suitable for various abrasion and wet scrubbing tests, which is commonly used in scrubbing resistance tests for interior wall paints, floor tiles, shower rooms, and furniture surfaces. Brush, sponge, scouring pad, sandpaper or other methods can be required to test the scrubbing resistance ability of the painted or uncoated surface. The abrasion resistance test can be carried out by adding abrasive or detergent using wet scrubbing method.
Standards compliant
JIS L0849-2013 Tests for color fastness to rubbing (type I);
JIS L0849-2013 Tests for color fastness to rubbing (type II);
JIS L1084-2009 Tests for flocking fabric (color fastness);
JIS L0862-1996 Tests for color fastness to rubbing : Organic solvent (type I);
JIS L0862-1996 Tests for color fastness to rubbing : Organic solvent (type II);
JIS P8136 Tests for abrasion resistance :cardboard ;
JIS L1084-2009 Tests for flocking fabric (flocking strength).
Major Features
Quick-change fixture design
The adjustable quick holder can be used to mount test samples of various thicknesses, easy and convenient.
Standard test accessories
The tester can be configured with a variety of standard test suites to meet different test needs while loading different loads.
Stainless steel body
The test board of the device is made of stainless steel, which can resist the corrosion of various liquids, and the appearance of stoving varnish is beautiful and durable.
Flexible and compact design
The flexible and compact design makes this tester easy to assemble, which can be installed and tested from the lab to the production line at anytime and anywhere.
Field Application
T107 Scrubbing Tester,It is suitable for brush, sponge, scouring pad, sandpaper or other methods that can be required to test the scrubbing resistance ability of the painted or uncoated surface.
It is applicable to the performance verification of new products, quality control of the production department, and the of material properties for the third-party testing organization, the product performance verification laboratory, and the quality and technical supervisiondepartment, etc.
Technical Parameters
|
Testmode: automatic |
Friction head weight: 454±10g |
|
Steel plate:454X165×6.3mm |
Glass plate size: 454×165×6.3mm |
|
Speed:37±1 cycles/min |
Weight: 20kg |
|
Brush holder: stainless steel, 3.2mm rubber mat |
Power supply: 220V 50Hz |
|
Substrate: black plastic plate 165X432×0.25mm, Leneta P121-10N |
Appearance size: 480mm*300mm*240mm |
Send product request
