KES - G5 Compression Tester

The Compression Tester analyzes hand movements-particularly, movements by finger-performed by artisans and professionals when judging a fabric's texture. The device performs this movement mechanically, making it possible to obtain objective numerical data while offering more enhanced versatility over the STD-FB3-A Compression Tester.

Obtainable data includes compression rigidity, compression energy, and recover ability.

The machine can be applied to a wide variety of fields and purposes, including determining the softness of disposable diapers and the hardness of mousse.

Standards

ASTM D903. ASTM E8 CNS11888. JIS K6854. PSTC7 ASTM D903、GB/T16491CNS-11888、JIS K6854. PSTC-7 、ASTM E4、ASTM D828、ASTM D882、ASTM、D1938、ASTM D 412 、ISO 8339、ASTM D3330、ASTM F88、ASTM F904、ISO 37、JIS P8113、QB/T 2358、QB/T 1130 、 ISO 527 、ISO 178 and other standards.

Features

Various attachment shapes

Choose from variously shaped compression sensors tailored to the sample being measured, for silicon material, how easy buttons can be pushed, car seats. etc.

Parameter

Product Name Compression Tester
Dimensions (W×D×H) *approx. Measuring unit: 190×230×460 mm
Amplifier: 180×400×400 mm
Weight *approx. Measuring unit: 11 kg
Amplifier: 13 kg
Power supply, Frequency 100VAC, 50/60Hz
Interface KES-USB (optional)
PC (optional)*1
Data logger output terminal
OS Windows 7/8/8.1/10
Sample size Square sample with a side of 20 to 100 mm (standard)
