Air Permeability Tester STD- F8
Whats/App: +86 156 1874 6768
Web: standard-groups.com
The Air Permeability Tester is designed to quickly and accurately measure the breathability and permeability of a wide range of samples, from those with high permeability, such as stockings, to those with low permeability, such as synthetic leather.
Samples can be mounted in just a few seconds using the handle, and measuring is also incredibly simple.
Standards
ISO 9237
GB/T 5453
DIN 53887
ASTM D737
AFNOR G07-111
Features
Highly accurate measurement using the constant ventilation method
The STD-F8 allows measurement of ventilation resistance. Compared with commonly used measuring methods, the STD-F8 is capable of highly accurate measurements. In addition, measurements can also be obtained with minute amounts of ventilation (measurement conditions similar to ventilation conditions when clothes are worn).
Parameter
| Product Name | Air Permeability Tester |
| Dimensions (W×D×H) *approx. | Measuring unit: 330×495×430 mm |
| Weight *approx. | Measuring unit: 25 kg |
| Power supply, Frequency | 100VAC, 50/60Hz |
| Interface | Data logger output terminal |
| Sample size | 50×50 to 100×100 mm (standard) Thickness: 1 mm (max.) Other sample sizes are able to be used with optional accessories. |
Optional Accessories
| Vent pressing plate (20 πcm², 0.2 πcm²) |
Vent sizes are variable. |
| Attachment provided for thick samples | To thickness 40 mm |
| Please contact us for more information. |
