Solar Cell Spread of Flame & Burning Brand Test Machine， IEC 61730
Productintroduction:
This apparatus is based on UL 1730. IEC 61730-2 design and development. Is to simulate real conditions to assess roof and components of fire-resistant performance of the instrument, in A1.82m, b 2.4mandc 3.9m specimens to evaluate A~C level. Also can be used infire-retardantperformance of photovoltaic components used in this test.
Standards:
•UL1730:multifamilyandhotelroomindividualdwellingunitsmokedetectionmonitors:electricsignaldetectionofhousedust;
•UL790:standardmethodoffiretestforroofcoveringmaterials;
•ASTMe108-04:standardmethodoffiretestforroofcoveringmaterials;
• NFPA256:firetestofroofdeck.
• IEC 61730-2Appendixb:firetestsonPVmodules.
Equipmentcharacteristic:
Structuralparts
1. Plywoodroofcoveringmaterials,dimensions:1.300(w)X1.000(d)x120(h),toinstallthetestsample;
2. Non-combustibilitytestBoard,installedattheendoftesting,canstopthetestpanelstempered;
3. Stainless steelfancontrolboard,thetestanglecan beadjusted,size:1.440(l)x940(h)mm;
4. Used to support the testing of the main frame bracket, corrosion-resistant steel, dimensions: 1.020 (l) x 1.000 (d) x 1.473 (h) mm;
5. Non-combustibleplateAssembly,installedinfrontof theframetosimulatetheeavesandcornice,extensionoftheflamefromtheburnertothespecimen,dimensions:330(w)x2.130(d)x584(h)mm;
6.Airflowrateforthetestpanel:19±8km/h(5.5M/sec),andconfiguretheanemometermonitor;
7. Separateventilationpipes,can beextractedfromoutsidethelaboratoryair;
8. Honeycombfilterisinstalledintheair duct,installedgasinletguidevane;
9. Ventilationductsequipped withslopeadjustmentpanelforadjustingtheairflow direction;
10. Ventilation pipes attached to the Guide, can enhance speed to ensure supply test airflow from the outside interference, guide plates made of stainless steel, location does not change with the wind pressure;
11. Duct materials for stainless steel, corrosion-resistant and heat-resistant, size: 2.130 (w) x 762 (h) x 3.000 (l) mm;
12. Fan 220V,50HZ, three-phase power, is equipped with a reverse system can automatically adjust wind speed, minimum flow for 300m3/min;
13. Infinitelyvariable speedinverter,0-100%adjustable;
14. Gas burners (for intermittent Shi Huo, flame spread and flying fire), 1.12m, 60.3mm, moving in the test side has a 12.7mm (w) *0.91m (long) slit;
15.Gasburner can provide a 22.000Btu/min (387kWh), and according to a, b, c three combustion levels, high-precision gas control valve controlling gas flow,
16. Topburnerthermocoupleisinstalled58.7mm,888±cantest28ºC;
17. Automatic ignition system, ensure the security of test performance, ignition electrode 1.8kVp mass flow controller is the minimum pressure according to different standards, control gas flow rates, Class A and B:21.000 ~ 22.000 Btu/min (369 ~ 387 kWh) for 10 minutes, Class C:18.000 ~ 19.000 Btu/min (316 ~ 334 kWh) 4 minutes;
18. Temperature control system-Class A and B:760±28ºC (1400±50ºF)-21.000 ~ 22.000 Btu/min-Class C:704±28 c (1300±50ºF)-18.000 ~ 19.000 Btu/min
19. High precision pressure gauges and pressure regulating valve controls the gas pressure;
1)-Eachtransfertogasintheburnersneedtofollowadifferenttestandcontrolmethods;
2)-LNG:usingMFMcanaccuratelymeasureflow(flowcontrolvalvecontrol);
3)-LPG:airflowrateusingtheinvertersystem:thetestdeckat19±8km/h(5.5M/sec);
20. Metallicmeshsupportmaterials,palletscan berotated,so thatfullcombustionofmaterials;
Testsection
1. Computer control system of United States special control software for Labview experiment, integration 10.2 "LCDscree;
2. Data acquisition systems, LabView programming language is used to program, data acquisition cards United States NI offers
3. Data acquisitionsystemconsistsof thefollowingparts:
1) 16-bitthermocoupleinputmodule
2) 16bita/dconversioninputmodule
3) Datainput/outputmodule
4) 12bita/dconversionoutputmodule
5) 4and8-slotbackplane
6) Labviewmodules
7) Labview/Ethernetnetworkmodule
4. Brand testing systems, gas burners, the flame engulfed the burning material, the gas burner is 880±10ºC temperature can be adjusted;
Thestandardresults
1. Generalstandardsforflamespread
• Any part of the roof covering materials (component or Panel) from the test deck in flame or glowing particles blown,
• Canslidethrough,split,curvedroofcoveringmaterials, such asroofdeckopen,
• FiresafetyratingA:flamespreadrangeis1.82M,
FiresafetylevelB:flamespreadrangeis2.4M,
Rank Cfiresafety:firespreadingareais3.9M,
Measuredfromtheedgeof thesamplespreadofflame,
2. Generalstandardsforroofcombustion
• Any part or component of the Panel from the test deck in flames blowing or falling,
• Parts of the roof deck or a part of a Panel in the roof structure or component in the form of luminous particles disappear,
• Continuewithcomponentsorpanelsofcombustion,
Equipmentspecification:
| Model | STD-UL1730 |
| Dimensions | About6.000(w)X2.200(d)X2.000(h)mm |
| Power supply | AC 380V 3-Phase, 50/60Hz, 50A |
| Weight | Approx. 850kg |
| Brochure | Canprovide |
| Exhaust | Minimum400 m2/min |
| Other Requirements | Propane gas/liquefied natural gas, Compressed air, Vacuum cleaners, Computer |
