Heat Storage Performance Tester provides standardized procedures and controls radiation heat conditions, providing repetitive measurement for heat storage and thermal transfer of protective fabric materials. Through measurement, the characteristics and rating of the material can be quickly identified, and the possibility of burn to the material is predicted through the integrated burn model of the instrument.

The equipment includes radiant heat source, sample holder, calorimeter induction component, pneumatic start transfer tray with water-cooled slide frame, compressor, DAQ/control system and combustion injury analysis program.
Instrument Features:
·Assessing the possibility of skin burns which is related to the heat energy storage performance of fabric.
·Automatic or manual test operation
·Radiant plate heat source (adjustable temperature) generates radiation energy, which matches with the spectral line density of building fire.
·The water-cooled sample sliders, electronic driven, realizes the precise control of the time of exposure on the heat source.
·The pneumatic compressor uses a low conductivity core bar to apply a 1PSI load on the sample.
·The system includes the integrated burn model, which predicts the severity of skin injuries, and calculates the estimated time of exposure leading to secondary burns.
·The combustion results are real-time values and the graph shows the skin layer interface temperature and combustion synthesis of Omega.

System Including:

·Dell PC laptop.
·ThermDAC software with a combustion model
·Signal conditioning circuit and USB interface
·Power supply and control cable, operator manual
·One-year warranty.

Laboratory Requirement:
·The laboratory should be well ventilated with dry compressed air source and cooling water supply pipe.
·The desktop device is designed for operation of horizontal or vertical radiant heat sources.
·It is recommended to operate in a vertical direction.

Standard Specification

·The radiant heat plate range is 0-0.25 CAL/cm2, adjustable.

·There are two types of hot plate operating modes: temperature control or heat flow control.
·The water-cooled sample slider supports sample and copper calorimeter exposes the sensor.
·Pneumatic control compression system
·The sample compression force can be adjusted by changing the air pressure in the cylinder.
·Sample size: 6x6ft (15x15cm). Gaskets with different thickness can be provided to compress the edges of smaller samples.
