Winner311XP droplet particle size analyzer for atomizer particle size distribution

Winner311xp is desktop spray laser particle size analyzer, with a number of patented technology including lens protection device. It could test size of droplet in the air without touch. It’s mainly apply to droplet detection of small spray equipment, such as medical atomizer,atomizing drugs and aerosol.

Main Specification:

Model

Winner 311XP

Size Range

  1. 00µm

Detector channels

40

Accuracy

<3%(Deviation of D50 on National standard samples)

Repeatability

<3%(Deviation of D50 on National standard samples)

Light source

Semiconductor λ= 650nmp>1mW

Feeding

open

Measurement area length

6cm

Dimension

L66*W26*H45cm

19KG

Main Features:

1)Unique patented technology

Based on laser scattering principle, adopt a single beam of parallel light path and

the dual-lens, dual-array detector technology to ensure high collection of scattering light at different angles, extends the measurement limit, improve the resolution of the instrument.

2)Unique air flow protection device

Airflow protection system can effectively protect the lens to avoid droplet pollution of the lens in the testing process.

3)For the national pharmacopoeia of inhaled aerosols, sprays, size requirements and the development of inhalation and other desktop spray laser particle size analyzer, can be a variety of aerosols, sprays and other small spray device for testing, integration of micro-nano the company a variety of patented technology, is the best choice of small spray particle size testing.
